192 / 1590
100° Hinges - Max. Door Thickness 15/16"
H W
B
overlay
37
11
T
66
Features
• Available in
Self-Close
• Three-dimensional adjustment
• Add-on BLUMOTION available
(B973A0500.01)H
B
overlay
11
66
T
Overlay Hinge (Straight Arm)
Item No.
Description List Ea. 50
Self-Close
B71M255Screw-on
$3.12
Frameless
Frame
Overlay
Example: Bore at 5 mm (3/16"), use a
0 mm baseplate = 16 mm (5/8") overlay.
Example: Bore at 5 mm (3/16"), use a
3 mm baseplate = 13 mm (1/2") overlay.
Minimum Reveal Table
3 0.5 0.9 1.1 1.4 2.3 3.6
4 0.5 0.8 1.0 1.3 2.0 3.3
5 0.4 0.8 1.0 1.2 1.8 3.0
6 0.4 0.8 0.9 1.1 1.7 2.8
B =
boring
distance
16 18 19 20 22 24
T = door thickness
For door thickness greater than
24 mm a trial is recommended.
H
Overlay
P
S
0 14 15 16 17 9 20
3 11 12 13 14 12 23
4.5 9.5 10.5 11.5 12.5 13.5 24.5
6
8
9 10 11 15 26
9
5
6
7
8 18 29
3
4
5
6
fixed
distance
= 11
B = boring distance
NOTE:
4.5 plate is only for use in frame cabinets,
9 plate is only for frameless cabinets
Abbreviations
H
= Plate height
P
= Door protrusion
S
= Side arm protrusion
T
= Door thickness
W
= Side panel width
Order hinges & baseplates separately.
See pages 216-220 for baseplate options.
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &
CLOSET
ORGANIZERS
KITCH./BATH
LIGHTING SLIDES
DOORS &
DRAWERS
LOCKS &
CATCHES
AVENTOS &
LIFTS
CABINET
HINGES
DECORATIVE
HARDWARE
CABINET HINGES
800.533.0533
2021
1946
192
Prices subject to change without notice.
CHARLESMCMURRAY.COM
