Charles McMurray Co. 2021 Catalog

193 / 1590

107° Hinges - Max. Door Thickness 7/8"
Frameless Cabinet Applications Frame Cabinet Applications
Features
• Available in Self-Close
• Three-dimensional adjustment
• 86˚ angle restriction clip available
• Use #10 insertion ram
• Add-on BLUMOTION available
Overlay Door Overlay Door
Example: Bore at 5 mm (3/16"), use a 0 mm baseplate = 16 mm (5/8") overlay.
Example: Bore at 5 mm (3/16"), use a 3 mm baseplate = 13 mm (1/2") overlay.
CLIP top Overlay Hinges (Straight Arm)
Item No. Description
List Ea.
50
List Ea.
250
Self-Close
Screw-on $3.68 $3.31
Press-in $3.90 $3.51
INSERTA $5.38 $4.84
CLIP Series Overlay Hinge
Item No. Description
List Ea.
50
List Ea.
250
Self-Close
Press-in $3.72 $3.34
To limit the opening angle of the Blum 107°
hinges to 86°.
Item No. Box List Ea.
List Ea.
100
100 $1.36 $1.00
Screws - Flathead Phillips
Screw-on hinges use #6 wood screws
.
Angle Restriction Clip
86°
Minimum Reveal Table
3 0.6 1.0 1.3
4 0.6 1.0 1.3
5 0.6 1.0 1.2
6 0.6 1.0 1.2
B =
boring
distance
16 18 19
T = door thickness
For door thickness greater than
19 mm a trial is recommended.
H Overlay P S
0 14 15 16 17 10 21
3 11 12 13 14 13 24
4.5 9.5 10.5 11.5 12.5 14.5 25.5
6 8 9 10 11 16 27
9 5 6 7 8 19 30
3 4 5 6 fixed
distance
= 11 B = boring distance
NOTE: 4.5 plate is only for use in face frame
cabinets, 9 plate is only for frameless cabinets
Abbreviations
H = Plate height
P = Door protrusion
S = Side arm protrusion
W = Side panel width
H
B
overlay
11.5
66
T
H W
B
overlay
37
T
66
11.5
Order hinges & baseplates separately.
See pages 216-220 for baseplate options.
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
CABINET HINGES
800.533.0533 2021 1946 193 Prices subject to change without notice.
