Light Gray (HG)
Calculate the power factor to determine the required lift mechanismset for your application. Cabinet height determines the telescopic
arm set required. *Calculate with theoretical cabinet height (TKH) for asymmetrical doors - the larger door must be at the top.
AVENTOS HF top Bi-Fold Door Lift System
Wood or Wide Aluminum Door for Panel and Face Frame Applications
Set includes two telescopic arms.
Set No. Cabinet Height List Set
480-610 (18-7/8 to 24") $93.38
600-910 (23-5/8 to 35-7/8") $114.42
840-1219 (33-1/8 to 48") $135.48
*For asymmetrical doors see TKH chart above.
4 separate items are required to complete unit:
Lift mechanism set, telescopic arm set, hardware set, and cover set. Order screws separately for
hardware set. NOTE: a pozidrive bit (B2X2POZIBIT) and torx T20 screwdriver are required
to make necessary adjustments.
Order a cover set
Set No. List Set
$47.50
$47.50
$47.50
Power Factor Set No. List Set
238-1188 $195.74
880-1698 $213.80
The power factor can be increased by 50% when using a third
lift mechanism.
Set includes (2) lift mechanisms and (8) #7 x 35mm (1-3/8")
wood screws. Use the more powerful lift mechanism for over-
lapping areas.
Minimum Cabinet Depth: 264 (10-3/8")
For large overlay face frame application.
Hardware Set includes
2 175H3F00 Telescopic arm mounting plates
2 32.4630 COMPACT 33 free-swing hinges
2 175H6000 CLIP face frame mounting plates
2 130.1130.02 COMPACT 33 mounting plates
2 78Z5530T CLIP top bottom door hinges
Set No. List Set
B78Z5530TA9 $59.92
For frameless/partial overlay face frame.
Hardware Set includes
2 175H3100 In-line mounting plates for lever
2 CLIP top 120˚ free-swing hinges
4 175H6000 CLIP face frame mounting plates
2 78Z5530T CLIP top center hinge
Set No. List Set
$59.92
SERVO-DRIVE for AVENTOS HF top see page 307a.
Order screws separately.
Item No. Door Type Description List
(12 required) Wood #6 x 5/8" $4.84c
For complete specifications order Blum catalog
or visit
Power factor (PF) = cabinet height* (") x combined door weight (lbs.) including handle weight.
Theoretical cabinet height (TKH) = door height top (") x 2 + gaps
Order a hardware set
Determine the power factor for the application
Order a lift mechanism set
Order a telescopic arm set
Cover Set includes
1 ea. LH/RH cover plate
2 ea. cover caps
1
2 4
3
5
11/24
11/24
480 (18-7/8") - 1219 (48")
door range
cabinet widths up to 1828 (72")
Don't know the door weight?
Call us...we can help! ?
Hardware set B78Z550AT6 for narrow aluminum applications available
by special order.
