Cam Height Adjustable - Center Mount
• Attach with #7 x 3/4" wood screws
• Steel, zinc die-cast and nickel-plated
• Center mount (9.5 mm)
• Cam height adjustment ±2 mm
Item No. Height Box
List Ea.
50
List Ea.
250
0 mm 250 $2.06 $1.96
3 mm 250 $2.30 $2.18
4.5 mm 250 $2.50 $2.42
6 mm 250 $2.72 $2.62
*Not for use with INSERTA hinges (use .
Off-Center Mount
• Attach with #7 x 3/4" wood screws
• Zinc die-cast, nickel-plated
• Height adjustment ±2 mm
Item No. Height Box
List Ea.
50
List Ea.
250
0 mm 500 $1.44 $1.36
3 mm 500 $1.54 $1.46
6 mm 250 $2.00 $1.92
Center Mount
• Attach with #7 x 3/4" wood screws
• Zinc die-cast, nickel-plated
• Height adjustment ±2 mm
Item No. Height Box
List Ea.
50
List Ea.
250
3 mm 500 $1.54 $1.48
Off-Center Mount with Flange
• Added flange for increased stability
• Off-center mount 12.5 (1/2")
• Attach with #7 x 3/4" wood screws (use all 4 screwholes)
• Zinc die-cast, nickel-plated
• Height adjustment ±2 mm
Item No. Height Box
List Ea.
50
List Ea.
250
0 mm 250 $2.90 $2.78
Recommended for use with 170°
and zero protrusion hinges
Cam Height Adjustable - For Inset Doors
Use with half-cranked hinges only.
• Attach with #8 x 3/4" trusshead screws
• Zinc die-cast, nickel-plated
• No build-up behind face frame is necessary
• Can be used on frames with applied bead moulding
• Cam height adjustment ±2 mm
• Use of template recommended
• Not recommended for wide angle hinges
Item No. Height Box List Ea. 50 List Ea. 250
9 mm 250 $4.28 $4.12
Boring
Distance (B)
Door
Gap (G)
6 (1/4") 1.6 (1/16")
5 (3/16") 2.6 (3/32")
4 (5/32") 3.6 (5/32")
3 (1/8") 4.6 (3/16")
