Charles McMurray Co. 2021 Catalog

216 / 1590

Cam Height Adjustable Wing Baseplates
• Use #6x5/8" wood screws
• Steel, nickel plated
• Cam height adjustment ±2 mm
Item No. Height Box List Ea.
0 mm 500 $1.10
3 mm 500 $1.35
Cam Mounting Plates - EXPANDO
• Pre-mounted EXPANDO dowels
• Steel, nickel plated
• Cam height adjustment ±2 mm
Item No. Height Color Box List Ea.
0 mm Nickel 500 $1.29
0 mm Black 500 $1.52
3 mm Nickel 500 $1.55
Cam Mounting Plates - INSERTA
• Pre-mounted Inserta dowels
• Steel (closing lever - zinc die-cast, nickel plated)
• Tool-free assembly with self-anchoring feature
• Cam height adjustment ±2 mm
Item No. Height Box List Ea.
0 mm 250 $2.74
• Use 5 mm euro screw or #7 wood screw
• Steel, nickel plated
• Cam height adjustment ±2 mm
Item No. Height Box List Ea.
0 mm 500 $1.12
3 mm 500 $1.42
Cam Mounting Plate - Euro Screw or Wood Screw
Baseplate Spacer
3mmspacer for CLIPbaseplates.Mounts
under baseplate and reduces overlay by
3 mm (1/8"). Gray nylon.
Item No. Box List Ea.
50 $0.84
• 20 mm setback, 32 mm apart
• Pre-mounted EXPANDO dowels
• Steel, nickel-plated
• Cam height adjustment ±2 mm
Item No. Height Box List Ea.
0 mm 500 $1.71
3 mm 500 $1.94
In-Line Cam Mounting Plate - EXPANDO
• 20 mm setback, 32 mm apart
• Use #6 wood screws
• Steel, nickel-plated
• Cam height adjustment ±2 mm
Item No. Height Color Box List Ea.
0 mm Nickel 500 $1.42
0 mm Black 500 $1.54
In-Line Cam Mounting Plate - Screw-On
32 20
H
*Add additional wood
screw if used with wide-
angle hinges.
*Add additional wood screw
if used with wide-angle
hinges.
* Add additional wood
screw if used with wide-
angle hinges.
*Add additional wood screw if
used with wide-angle hinges.
*Addadditionalwoodscrew ifused
with wide-angle hinges.
* Add additional wood screw if
used with wide-angle hinges.
BK = Onyx Black
Cam Mounting Plates - Screw-On
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
CABINET HINGES
800.533.0533 2021 1946 216 Prices subject to change without notice.
