One-Piece Mounting Plate - Screw-On

• Attach with #6 x 5/8" wood screws

• Steel, nickel-plated

• Height adjustment ±3 mm

Item No. Height

Attachment

Box List Ea.

B173L6100

0 mm #6 x 5/8" FHPH 500 $0.64

• Pre-mounted 5 mm euro screws

• Height adjustment ±3 mm

Item No. Height

Attachment

Box List Ea.

B173L8100

0 mm 5 mm Euro Screw 500 $0.73

B173L8130

3 mm 5 mm Euro Screw 500 $0.92

B175L8100

0 mm 5 mm Euro Screw 500 $1.72

B175L8190

9 mm 5 mm Euro Screw 250 $3.08

One-Piece Mounting Plates -

Mounted Euro Screw

B173L

One-Piece Mounting Plate - EXPANDO

Two-Piece Mounting Plates - Screw-On

Two-Piece Mounting Plates - Euro Screw

• Attach with #6 x 5/8" wood screws

• Zinc die-cast, nickel-plated

• Height adjustment ±2 mm

Item No. Height

Attachment

Box List Ea.

B175H7100

0 mm #6 x 5/8" FHPH 500 $1.86

B175H7130

3 mm #6 x 5/8" FHPH 500 $2.48

B175H7190

9 mm #6 x 5/8" FHPH 250 $3.18

• Attach with 5 mm euro screws

or #7 wood screws

• Zinc die-cast, nickel-plated

• Height adjustment ±2 mm

Item No.

Height Attachment

Box List Ea.

B175H9100

0 mm 5 mm Euro or #7 500 $1.85

B175H9130

3 mm 5 mm Euro or #7 250 $2.38

B175H9160

6 mm 5 mm Euro or #7 250 $2.94

B175H9190

9 mm 5 mm Euro or #7 250 $3.18

B175H919022

18 mm 5 mm Euro or #7 250 $4.60

• Pre-mounted EXPANDO dowels

• Steel, nickel-plated

• Height adjustment ±2 mm

Item No. Height Attachment

Box List Ea.

B174E6100

0 mm EXPANDO Dowel

500 $0.82

Steel, nickel-plated

*

Add additional wood screw if used with wide-angle hinges.

Zinc die-cast, nickel-plated

*

Add additional wood screw if used with wide-angle hinges.

B175L

*

Add additional wood screw if

used with wide-angle hinges.

*

*

Add additional wood screw

if used with wide-angle

hinges.

*

Add additional wood

screw if used with wide-

angle hinges.

*

Add additional wood screw

if used with wide-angle

hinges.

0mm

9mm
