105° Opening Short Arm No Baseplate
1-1/4" Overlay, Soft-Closing
Screws not included.
Each hinge requires: 6ea #6x5/8" panhead screws )
2ea #8x1/2" washerhead screws
Item No. Box List Ea. List Ea. 100
100 $31.36 $26.04
• Surface mounted
• Works on all doors; Flush overlay, 3/8" inset, full inset
• Fits doors up to 3/4" thick
• 4-way adjustable
Surface Mounted Concealed Hinge
165° Opening, Self-Closing
3/4" Overlay
1-3/16" 7/16"
1-7/8" 1-13/16"
4-3/16" 3-7/8"
1-5/8"
Cabinet Door
3/32"
Straight EdgeCabinet Door
*3/4" thick door
11/16" 3/8"
1-7/8" 1-13/16"
4-3/16" 3-7/8"
9/16"
Cabinet Door
1/8"
Straight EdgeCabinet Door
3/8"
3/4"
4-3/16"
washerhead
screws here
5/16"
1-1/4"
4-3/4"
2-3/4" 1-13/16"
Cabinet Door
2-7/16"
Straight Edge
Cabinet
Door
3/8" Inset
Full Inset
1-1/4" overlay doweled hinge. 35 mm hinge cup. 4-way adjustable.
Dowels are 45 mm apart.
Item No. Description List Ea.
List Ea.
50
List Ea.
200
H297-D-SC Doweled $6.02 $5.62 $4.96
