J95-24 Heavy-Duty Concealed Hinge
1" Overlay, up to 93° Opening
• Load rating: 55 lbs./2pcs., 88 lbs./3pcs.
• Maximum door width: 31-1/2"/2pcs., 35-7/16"/3pcs.
• Clip-on type for easy installation
• 3-way adjustment on baseplate, with door installed
• Suggested screws: #7 x 5/8"
QS14470 #7 x 5/8" (Stainless)
MCFPT347NI #7 x 3/4"
• Optional spacer, hinge and baseplate covers available
hinge shown w/baseplate (sold separately) baseplate sold
separately
Order hinge and baseplate separately. Sold per each. Screws not
included.
Item No. Description Box List Ea.
List Ea.
Full Box
Self-Closing Hinge 10 $44.48 $37.70
Free-Swinging Hinge 10 $44.48 $37.70
0 mm Baseplate 10 $16.98 $14.44
Free-Swinging Hinge Spacer: Decreases overlay of outset doors or
increases clearance of inset doors by 5/64" (2mm) - can be doubled.
Gray, plastic. Requires 5x25mm self-tapping screw.
Screws not included. Sold per each.
Item No. Box List Ea.
List Ea.
Full Box
100 $1.72 $1.40
Baseplate adjustments
Vertical ±3 mm (±1/8")
Overlay 0/-4 mm (±5/32")
Depth +1.5/-2.5 mm (±5/32")
