DOOR LOCKS & HARDWARE
800.533.0533 1287g Prices subject to change without notice.
McMurray.com
09/24
AN161 3D FVZ ANSELMI Hinges
• For use in wood or aluminum residential doors with up to
14 mm (1/2") recessed frame facing
• Central installation
• Non-handed
• Optional milling frame and template (order separately)
• 5-11/16"H
Specifications
Door weight 132 lbs. (w/ 2 hinges)
Door size 35-7/16" x 82-11/16"
Door thickness 40 mm (1-1/2")
Opening angle 180°
Router bit 12.7 mm (1/2")
Router guide 25.4 mm (1")
Adjustment
Height and width ± 3 mm (1/8")
Depth ± 1.0 mm (1/16")
Hinges include installation screws. Sold per each.
Item No. Finish List Ea.
Black $126.92
Satin Nickel Coated $126.92
Black Satin Nickel Coated
Installation tools:
Universal milling frame, includes frame and clamping device.
Sold per each. (Order templates separately.)
Item No. List Ea.
TE-MILLING-FRAME $1,101.69
Routing templates, sold per each.
Item No. List Ea.
$156.61
See pg. 1114a for details.
Mounted to a commercial
wood door frame
Mounted to a wood door
frame with casing
