TE640 3D TECTUS Hinges
• For use in wood or metal flush high performance commercial doors
• Maintenance-free slide bearings
• Non-handed
• UL listed for 20 minute fire-rated doors
• Optional milling frame and templates (order separately)
• 9-7/16"H
Specifications
Door weight 440 lbs.* (w/ 2 hinges)
Door thickness 40 mm (1-5/8")
Opening angle 180°
Router bit 24 mm (3/4")
Router guide 30 mm (1")
Adjustment
Height and width ± 3 mm (1/8")
Depth ± 1.0 mm (1/16")
*Reduce load by 20%when installing with door closer.
Hinges include covercaps and installation screws. Sold per each.
Item No. Finish List Ea.
Matte Deep Black $589.73
Satin Chrome Look (F1) $456.62
Satin Nickel Look (F2) $456.62
Matte Deep Black Satin Chrome Look
(F1)
Installation tools:
Universal milling frame, includes frame and clamping device.
Sold per each. (Order templates separately.)
Item No. List Ea.
TE-MILLING-FRAME $1,101.69
Routing templates, sold per kit.
Kit No. List Kit
TE640-3D-TMP $266.95
See pg. 1114a for details and kit components.
Fixing plates and receivers, sold per each.
Item No. Description List Ea.
Wood frame fixing plate w/shims $40.24
Metal door receiver $68.11
Metal frame receiver $75.84
Metal frame receiver, stainless steel $114.54
Mounting brackets for heavy duty cladded* doors, 264 lb. weight
rating (w/2 hinges). Sold per each.
Item No. Finish
Cladding
(ea. side) List Ea.
Mill Finish 5/8" $72.75
Mill Finish 13/16" $72.75
Deep Matte Black 3/4" $230.63
Satin Chrome Look (F1) 3/4" $184.20
*Cladding must be removed before bracket installation.
NOTE: For optimum opening with BW1 bracket, lock side of
door leaf may need to be champfered or beveled.
Fixing plate
for wood
door frame
11-1/16"H x
3-3/8"W
BW16/BW20
Mounting bracket
10-1/4"H x 1-1/4"W
BW1
Mounting bracket
with cover plate
9-1/2"H x 2"W
Receiver for
metal door
11-1/4"H x
1-1/2"W
Receiver for
metal door
frame
11-1/4"H x
1-1/2"W
Mounted to a commercial
wood door frame
Mounted to a hollow
metal frame
Mounted to a wood door
frame with casing
See pg. 1286d for replacement covercaps.
