AN108 3D SC45 ANSELMI Hinges
With Self-Close
• For use in wood or aluminum residential doors
• Integrated damping function, closing speed may be adjusted
after installation
• Non-handed
• 4-5/16"H
Specifications
Door weight 99 lbs. (w/ 1 hinge per door*)
Door size 35-7/16" x 82-11/16"
Opening angle 180°
Router bit 12.7 mm (1/2")
Router guide 25.4 mm (1")
Adjustment
Height ± 2.5 mm (1/8")
Width and Depth ± 1.0-1.5 mm (1/16")
*Must be used with (2) AN160-3D hinges, self-closing
hinge must be installed at center of door leaf. Black Traffic White
Mounted to a commercial wood door frame
Mounted to a wood door frame with casing
Front view
Set includes (1) self-closing hinge and (2) AN160-3D hinges
include installation screws. Sold per set.
Item No. Finish List Ea.
Black $660.93
Satin Nickel $660.93
Traffic White $660.93
