Charles McMurray Co. 2023 Catalog

1242a / 1645

Residential-Duty Locksets
Finishes
15
26 Polished Chrome
514 Matte Black
07/23
Item No. Function Finishes List Ea.
AL Passage 15† $71.40
514† $75.00
AL Privacy 15† $74.70
514† $78.30
AL Entry 15† $124.30
514† $127.90
AL Half Dummy 15† $35.70
514† $37.50
Item No. Function Finishes List Ea.
ALSQT Passage 15† $71.40
514† $75.00
ALSQT Privacy 15† $74.70
514† $78.30
ALSQT Entry 15† $124.30
514† $127.90
ALSQT Half Dummy 15† $35.70
514† $37.50
Katella Levers (KAL) Singapore Levers (SAL)
passage
(514) passage
(514)
half dummy
(514) half dummy
(514)
privacy (15)
(push-button interior) privacy (15)
(push-button interior)
entry (15)
(turn-button interior)
entry (15)
(turn-button interior)
NOTES:
Privacy has push-button interior, entry has turn-button interior.
For strikes see catalog page 1251.
Prices shown are Kwikset's List Prices from August 2024 Box Pack Price Guide.
(Passage
& privacy
function
only)
Door Prep: Crossbore 2-1/8", Edge Bore 1",
Latch Face 1" x 2-1/4"
Backset: Adjustable to 2-3/8" or 2-3/4"
Door: 1-3/8" to 1-3/4"
Faceplate: 1" x 2-1/4"
Strike: 2-1/4" full lip
Cylinder: SmartKey
Bolt: 1/2" throw
ANSI/BHMA: Grade 2
ADA: 720 & 730 functions ANSI A117.1
Warranty: Lifetime mechanical & finish
Exterior Dimensions
Style A B C C (entry)
Katella 2-21/32" 4-1/4" 2-15/32" 2-9/16"
Singapore 2-11/16" 4-7/32" 2-1/2" 2-1/4"
† Features Microban® Protection
