Charles McMurray Co. 2023 Catalog

1242b / 1645

Residential-Duty Locksets
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 1242b Prices subject to change without notice.
McMurray.com
04/24
Finishes
4 Satin Brass
15 Satin Nickel
514 Matte Black
Item No. Function Finishes List Ea.
EL Passage 15 † $71.40
4 †, 514† $75.00
EL Privacy 15 † $74.70
4 †, 514† $78.30
EL-SMT Entry 15 † $124.30
4 †, 514† $127.90
EL* Half Dummy 15† $35.70
4 †, 514† $37.50
*Specify left or right-hand door.
Sedona Levers (SEL)
passage
(514)
half dummy
(514)
privacy (4)
(push-button interior)
entry (15)
(turn-button interior)
NOTES:
For strikes see catalog page 1251.
Prices shown are Kwikset's List Prices from August 2024 Box Pack Price Guide.
(Passage
& privacy
function
only)
Door Prep: Crossbore 2-1/8", Edge Bore 1",
Backset: Adjustable to 2-3/8" or 2-3/4"
Door: 1-3/8" to 1-3/4"
Faceplate: 1" x 2-1/4"
Strike: 2-1/4" full lip
Cylinder: SmartKey
Bolt: 1/2" throw
ANSI/BHMA: Grade AAA
ADA: 720 & 730 functions ANSI A117.1
Warranty: Lifetime mechanical & finish
Exterior Dimensions
Style A B B (entry) C C (entry)
Sedona 2-21/32" 4-1/4" 4-9/32" 2-17/32" 2-5/16"
† Features Microban® Protection
