Door Prep: Crossbore 2-1/8", Edge Bore 1"
Backset: Adjustable to 2-3/8" or 2-3/4"
Door: 1-3/8" to 1-3/4"
Faceplate: 1" x 2-1/4"
Strike: 2-1/4" full lip, 1/4" radius corner
Cylinder: SmartKey (RDT & SQT) or 5-pin (RDT only)
Bolt: 1/2" throw
ANSI/BHMA: Grade 3 (except 488)
ADA: RDT satisfies 4.13.9 ADA requirements except 488
SQT functions 200 & 420 meet ANSI A117.1 and ADA requirements
Exterior Dimensions
Style A B C C (Entry)
Ladera 2-5/8" 4-3/16" 1-7/8" 2-7/16"
(200 & 420)
Ladera Levers (LRLSQT)
Item No. Function Finishes Case List Ea.
Passage 15†, 26 12 $48.60
514 † 12 $51.60
Privacy 15†, 26 12 $51.60
514 † 12 $54.60
Half Dummy 15†, 26 12 $24.30
514 12 $25.80
Entry With SmartKey
-SMT Entry 15†, 26 12 $72.10
514 † 12 $75.10
*Specify left or right-hand door.
Passage (200)
Privacy (300)
Dummy (488)
Entry w/SmartKey
(405)
(except 488
dummy)
Ladera Levers (LRLRDT)
Item No. Function Finishes Case
List
Ea.
Passage 15 †, 26, 514† 20 $48.60
Privacy 15 †, 26, 514† 20 $51.60
Half Dummy 15 †, 26, 514 20 $24.30
Entry With SmartKey
-SMT Entry 15 † 20 $72.10
514 † 20 $75.10
*Specify left or right-hand door.
Passage (200)
Privacy (300)
Dummy (488)
Entry w/SmartKey
(405)
NOTES:
Privacy and entry have push-button on interior. For latches and strikes see catalog page 1251.
Prices shown are Kwikset's List Prices from August 2024 Box Pack Price Guide.
Finishes
15
26 Polished Chrome
514 Matte Black
† Features Microban® Protection
