Charles McMurray Co. 2023 Catalog

1243 / 1645

Lisbon Levers (LSLSQT)
(except 157
dummy)
Door Prep: Crossbore 2-1/8", Edge Bore 1"
Backset: Adjustable to 2-3/8" or 2-3/4"
Door: 1-3/8" to 1-3/4"
Faceplate: 1" x 2-1/4", 1/4" radius corner
Strike: 2-1/4" full lip, 1/4" radius corner
Cylinder: SmartKey, square spindle
Bolt: 1/2" throw
ANSI/BHMA: Grade 2 (except 157)
ADA: Satifies 4.13.9 ADA requirements (except 157)
Exterior Dimensions
A B C C (entry)
2-5/8" 4-5/32" 2-9/16" 2-3/8"
Item No. Function Finishes Case List Ea.
Passage 514 12 $75.00
Privacy 15† 12 $74.70
514 12 $78.30
Entry 15† 12 $124.30
514 12 $127.90
Half Dummy 15†, 514 20 $37.50
NOTES:
Privacy and entry have push-button on interior.
For strikes see catalog page 1251.
Prices shown are Kwikset's List Prices from August 2024 Box Pack Price Guide.
Finishes
11P Venetian Bronze
15
514 Matte Black
† Features Microban® Protection
passage
(514)
half dummy
(15)
privacy (15)
(push-button interior)
entry (514)
(push-button interior)
Residential-Duty Locksets
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 1243 Prices subject to change without notice.
