Charles McMurray Co. 2023 Catalog

1244 / 1645

Door Prep: Crossbore 2-1/8", Edge Bore 1"
Backset: Adjustable to 2-3/8" or 2-3/4"
Door: 1-3/8" to 1-3/4"
Cylinder: SmartKey
Faceplate: 1" x 2-1/4", 1/4" radius corner
Strike: 2-1/4" full lip, 1/4" radius corner
Bolt: 1/2" throw, nickel plated
ANSI Standard: Trafford, Grade AAA (A156.30); Tustin, Grade 2
ADA: Trafford, Functions 720 & 730 satisfy ADA requirements;
Tustin, Function 720 satisfies ADA requirements (ANSI A117.1 compliance)
(Passage
& dummy
functions)
Lever A B C C (entry)
Trafford 2-21/32" 4-5/32" 2-19/32" 2-9/16"
Tustin 2-5/8" 4-1/4" 2-3/32" 2-19/32"
Tustin Levers (TNL)
Item No. Function Finishes Case List Ea.
Passage 11P †, 15†, 26 20 $60.60
514 † 20 $64.20
Privacy 11P †, 15†, 26 20 $63.90
514 † 20 $67.50
Entry 11P †, 15†, 26 20 $89.50
514 † 20 $93.10
Half Dummy 11P †, 26 20 $30.30
514 † 20 $32.10
*Specify left or right-hand door.
NOTES:
For latches and strikes see catalog page 1251.
Prices shown are Kwikset's List Prices from August 2024 Box Pack Price Guide.
Finishes
11P Venetian Bronze 26 Polished Chrome
15 514 Matte Black
† Features Microban® Protection
passage
(15)
half dummy
(15)
privacy (514)
(turn-button interior)
entry (11P)
(turn-button interior)
Residential-Duty Locksets
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 1244 Prices subject to change without notice.
McMurray.com
05/24 Trafford Levers (TDL)
Item No. Function Finishes Case List Ea.
Passage 15† 12 $71.40
514 † 12 $75.00
Privacy 15† 12 $74.70
514 † 12 $78.30
-SMT Entry 15† 12 $124.30
514 † 12 $127.90
Half Dummy 15† 20 $35.70
514 † 20 $37.50
passage
(15)
half dummy
(15)
privacy (514)
(push-button interior)
entry (514)
(turn-button interior)
