Charles McMurray Co. 2023 Catalog

1245 / 1645

Door Prep: Crossbore 2-1/8", Edge Bore 1"
Backset: Adjustable to 2-3/8" or 2-3/4"
Door: 1-3/8" to 1-3/4"
Faceplate: 1" x 2-1/4", 1/4" radius corner
Strike: 2-1/4" full lip, 1/4" radius corner
Cylinder: SmartKey or 5-pin
Bolt: 1/2" throw
ANSI/BHMA: A156.2 Grade 3 (except 488)
ADA: Satisfies 4.13.9ADA requirements (except 488)
Exterior Dimensions
Style A B C C (Entry)
Balboa 2-5/8" 4-7/32" 1-15/16" 2-13/32"
Dorian 2-5/8" 3-3/4" 2-1/8" 2-11/16"
Balboa Levers (BL)
(except 488
dummy)
NOTES:
For latches and strikes see catalog page 1251.
Prices shown are Kwikset's List Prices from August 2024 Box Pack Price Guide.
Finishes
11P Venetian Bronze
15
Stocked KA4
(Passage
function only)
Dorian Levers (DNL)
Item No. Function Finishes Case List Ea.
Passage 11P†, 15† 20 $48.60
Privacy 11P †, 15† 20 $51.60
Half Dummy 11P†, 15† 20 $24.30
Entry w/SmartKey
SMT Entry 11P †, 15† 20 $72.10
Entry w/Pin & Tumbler
Entry 11P †, 15† 20 $67.10
Stocked KA4
† Features Microban® Protection
Item No. Function Finishes Case List Ea.
Passage 11P† , 15† 20 $48.60
Privacy 11P† , 15† 20 $51.60
Half Dummy 11P† , 15† 20 $24.30
Entry w/SmartKey
-SMT Entry 11P† , 15† 20 $72.10
*Specify left or right-hand door.
