Charles McMurray Co. 2023 Catalog

1253 / 1645

980 Single Cylinder
Item No. Finishes Case List Ea.
11P†, 15† 12 $92.20
514 12 $96.00
980 Series Deadbolts
Door Prep: Crossbore 2-1/8" or 1-1/2", Edge Bore 1"
Backset: 2-3/8" or 2-3/4" adjustable deadbolt latch
Door Thickness: 1-3/4" only
Cylinder: SmartKey
Faceplate: 1" x 2-1/4", 1/4" radius corner
Strike: 1-1/4" x 3-5/8", 1/4" radius corner
Bolt: Brass bolt, 1" throw, Titaniumalloy throwbolt core
ANSI/BHMA: A156.5. Grade 1
ADA: Interior turn piece satisfies section 4.13.9 ADA
requirements
780 Single Cylinder
Item No. Finishes Case List Ea.
1/4 Radius Latch & 83223 Strike
3† 12 $68.30
11P, 15†, 26D 12 $78.20
780 Series Deadbolts
Door Prep: Crossbore 2-1/8" or 1-1/2", Edge Bore 1"
Backset: 2-3/8" or 2-3/4" adjustable latch
Door Thickness: 1-3/8" to 1-3/4"
Cylinder: SmartKey
Faceplate: 1" x 2-1/4", 1/4" radius corner
Strike: 1-1/4" x 3-5/8", 1/4" radius corner
Bolt: 1" throw, stainless steel
ANSI/BHMA: A156.5. Grade 2
ADA: Satisfies section 4.13.9 ADA requirements
Dimensions
Style A B C
780 Exterior 2-5/8" 1-1/8" -
785 Exterior 2-5/8" 1-1/8" -
780 Interior 2-1/2" 15/16" 1-25/32"
785 Interior 2-5/8" 1-1/8" -
Dimensions
Style A B C
980 Exterior 2-5/8" 1-1/32" -
980 Interior 2-19/32" 1-5/32" 1-13/16"
Finishes
3 Polished Brass 26D Satin Chrome
11P Venetian Bronze 514 Matte Black
15
NOTES:
Deadbolts are stocked KA3.
For latches and strikes see catalog page 1251.
Prices shown are Kwikset's List Prices from August 2024 Box Pack Price Guide.
† Features Microban® Protection
