Charles McMurray Co. 2023 Catalog

1238 / 1645

Active Exterior Trim Designs
Item No. Style Finishes List Ea.
SmartKey
SMT Amador 15 †, 26 $189.80
514 $199.00
SMT Belleview 15 $151.20
SMT Dakota 11P, 15 $151.20
Exterior Handle Only (no deadbolt)
Item No. Style Finishes List Ea.
Amador 514 $166.00
Dakota 15 $113.20
687 Series Standard-Duty Handlesets
Dakota
(15)
Door Prep: Deadbolt: Crossbore 2-1/8" or 1-1/2", Edge Bore 1".
Handle: Crossbore 2-1/8", Edge Bore 1"
Backset: Deadbolt: 2-3/8" or 2-3/4"
Handle: 2-3/8" or 2-3/4"
Door Thickness: 1-3/4"
Cylinder: 5-pin
Faceplates: 1" x 2-1/4", 1/4" radius corner
Strikes: Deadbolt: 1" x 2-1/4", 1/4" radius corner
Handle: 2-1/4" full lip, 1/4" radius corner
Bolts: Deadbolt: 1" throw
Handle: 1/2" throw
ANSI/BHMA: A156.5 Grade 3 deadbolt
Style A B
Amador 9-11/16" 17-15/32"
Belleview 8-13/32" 18-1/16"
Dakota 8-13/32" 17-3/16"
Belleview
(15)
Amador
(514)
Prices shown are Kwikset's List Prices
from August 2024 Box Pack Price Guide.
Order exterior and interior trims separately.
Finishes
3 Polished Brass 26 Polished Chrome
11P Venetian Bronze 514 Matte Black
15
Universal Active Int. Trim Designs for 687/800 Series
Item No. Style Finishes List Ea.
Aliso Knob 15 $53.70
Balboa Lever 11P, 15 $72.90
Breton Lever 514 $72.90
Casey Lever 15, 26, 514 $72.90
Cove Knob 11P, 15 $59.00
Dorian Lever 11P, 15 $72.90
Halifax 15, 514 $81.00
Ladera Lever 15, 26, 514 $72.90
Ladera Lever 15, 26, 514 $72.90
Polo Knob 11P, 15, 26 $59.00
Tustin Lever 11P, 15 $81.00
*Specify left or right-hand door.
† Features Microban® Protection
