Charles McMurray Co. 2023 Catalog

1236 / 1645

NOTES: You must use KW971/973 interior trims with
these handlesets. KW971/973 interior trims cannot be
used with other handleset series.
Prices shown are Kwikset's List Prices
from August 2024 Box Pack Price Guide.
Door Prep: Cross Bore: 2-1/8"
Edge Bore:1"
Latch Face: 1" x 2-1/4"
Backset Adjustable 2-3/8" or 2-3/4"
Door Thickness: 1-3/4"
Cylinder: SmartKey
Faceplate: 1" x 2-1/4", radius corner
Strikes Deadbolt: 1-1/4" x 3-5/8", 1/4" radius corner
Prescott deadbolt 1-1/8" x 2-3/4"
Handle: 2-1/4" full lip 1/4" radius corner
Bolts Deadbolt: 1" throw
Handle: 1/2" throw
ANSI/BHMA: Deadbolt is Grade 1
Vancouver, Prescott deadbolt Grade AAA
Lifetime warranty on finish & mechanical
Style A B C D
Prescott 2-25/32" 5-1/2" 8-13/32"-9-11/16" 17-3/4"
San Clemente 2-5/8" 5-1/2" 8-13/32"-9-11/16" 17-15/16"
Vancouver 2-5/8" 5-1/2" 8-13/32"-9-11/16" 17-15/16"
Trim Measurements
Style A B C
San Clemente 3-1/2" 4-5/8" 2-3/16"
Vancouver 9-1/8" --- 2-3/16"
2-3/4"
2-3/4"
A
B
3"
C
Exterior Trim Designs
Active Exterior Trims
Item No. Style Finishes List Ea.
Prescott 15† $296.00
514† $307.30
San Clemente 11P †, 15† $327.80
4, 514† $339.10
Vancouver 11P†, 15† $340.20
514† $351.50
Dummy Exterior Trims
Item No. Style Finishes List Ea.
San Clemente 11P, 15 $293.80
514 $305.10
Vancouver 15† $306.20
514† $317.50
818/819 Series Heavy-Duty Handlesets
Order exterior and interior trims separately. Interior trims are shown below.
A
C
2-3/4"
3"
818 Prescott
(15)
818 San Clemente
(15)
818 Vancouver
(15)
Interior Trim Designs
Active Interior Trims - Single Cylinder Deadbolt
Item No. Style Finishes
List
Ea.
Breton Lever - Sq Bkplate 514 † $72.90
Casey Lever - Sq Bkplate 15†, 514† $72.90
HalifaxLever - RectangleBkplate 514 † $81.00
Halifax Lever - Full Sq Bkplate 514 † $92.30
Halifax Lever - Sq Bkplate 4, 11P † , 15† , 514† $81.00
Katella Lever - Round Bkplate 15†, 514† $81.00
Lisbon Lever - Sq Bkplate 15†, 514 $81.00
Milan Lever - Round Bkplate 15, 514 $81.00
Pismo Knob - Round Bkplate 15 †, 514† $67.20
Pismo Knob - Sq Bkplate 11P†, 15†, 26, 514† $67.20
KW971SEL* Sedona Lever 4†, 15†, 514 † $81.00
QT Singapore Lever - Sq Bkplate 15†, 514 $81.00
KW971TDL Trafford Lever 15 †, 514† $81.00
*Specify left or right-hand door.
Dummy Interior Trims for 819 Series
Item No. Style Finishes
List
Ea.
HalifaxLever - RectangleBkplate 514 † $67.20
Halifax Lever - Sq Bkplate 11P, 15, 514 $67.20
Lisbon Lever - Sq Bkplate 15, 514 $67.20
Milan Lever - Round Bkplate 15 $67.20
Pismo Knob - Sq Bkplate 26, 514 $53.40
Interior Trim - Halifax
Lever with a Full
Square Backplate
† Features Microban® Protection
4
Satin
Brass
11P
Venetian
Bronze
15
Satin
Nickel
26
Polished
Chrome
514
Matte
Black
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 1236 Prices subject to change without notice.
