Charles McMurray Co. 2021 Catalog

421 / 1590

• Lateral self-alignment 3 mm (1/8")
• Non-handed, one-piece stamped steel design, zinc-coated
• Not for use with 9" or heavy-duty runners
• One pair required per drawer
• 50 pair per box, sold per pair without screws
• Use #6 x 1/2" trusshead screws
Item No. List Pair
List Pair
50
$4.06 $3.24
• For applications with side recess space limitations (end panel)
• Maximum dynamic load capacity 45 lbs.
• Lateral self-alignment 3 mm (1/8")
• Non-handed, one-piece stamped steel design, zinc-coated
• Maximum inside cabinet depth is 15 (19/32") less than allows
• Not for use with 9" or heavy-duty runners
• One pair required per drawer
• 50 pair per box, sold per pair without screws
• Use #6 x 1/2" trusshead screws
Item No. List Pair
List Pair
50
$7.02 $5.58
• Lateral self-alignment feature
• Non-handed, two-piece design
• Synthetic, natural color
• Non-detachable 8 mm (5/16") dowels, 9.5 mm (3/8") long
• 6 (1/4") minimum back panel thickness
• Not for use with 9" or heavy-duty runners
• One pair required per drawer
• 50 pair per box, sold per pair
Item No. List Pair
List Pair
50
$9.66 $6.76
TANDEM Accessories for 563 H/F Series
Rear Brackets for Face Frame Application
face frame stile
face frame rail
9 (11/32")
37
(1-15/32")
6.5 (1/4")
2
(3/32")
19(3/4") 40
(1-9/16")
• Lateral self-alignment feature
• Non-handed, two-piece design
• Synthetic, natural color
• Not for use with 9" or heavy-duty runners
• One pair required per drawer
• 50 pair per box, sold per pair without screws
• Use #6 x 1/2" trusshead screws
Item No. List Pair
List Pair
50
$11.36 $8.52
Screw-On Bracket
Narrow Screw-On Bracket
Plug-In Socket
Screw-On Socket
2-7/8"
2-7/8"
