Charles McMurray Co. 2021 Catalog

420 / 1590

• Captive right device and self-aligning left device
• Self-adjusting drawer length tolerance
• Steel base with synthetic, spring-loaded release levers
• Minimum inside drawer width 170 (6-11/16")
• Height adjustment +3 (1/8")
• Side adjustment ±1.5 (1/16")
Item No. Box List Pair List Pair Full Box
100 pr $7.96 $6.76
• Used to minimize sub front splitting
• Captive right device and self-aligning left device
• Self-adjusting drawer length tolerance
• Steel base with synthetic, spring-loaded release levers
• Minimum inside drawer width 170 (6-11/16")
• Height adjustment +3 (1/8")
• Side adjustment ±1.5 (1/16")
• Minimum sub front thickness 16 (5/8")
• Designed for 13 (1/2") drawer bottom recess
Item No. Box List Pair List Pair Full Box
100 pr $9.76 $8.28
• Captive right device and self-aligning left device
• Self-adjusting drawer length tolerance
• Steel base with synthetic, spring-loaded release levers
• Minimum inside drawer width 170 (6-11/16")
• Height adjustment +3 (1/8")
• Side adjustment ±1.5 (1/16")
• Depth adjustment +2.5 (3/32") out, preset at 0
• Minimum sub front thickness 13 (1/2")
• Designed for 13 (1/2") drawer bottom recess
• Integrated 3 (1/8") distance bumper for inset or overlay
SERVO-DRIVE applications
Item No. Box List Pair List Pair Full Box
100 pr $18.00 $15.32
Locking Devices for 563 Series Only
Standard
WITH Side Adjustment WITHOUT Side Adjustment
• Maximum dynamic load capacity 25 lbs.
• Captive right device and self-aligning left device
• Self-adjusting drawer length tolerance
• Vertical mount, two-piece nylon
• Minimum inside drawer width 95 (3-3/4")
• Height adjustment +3 (1/8")
• Minimum sub front thickness 16 (5/8")
• Designed for 13 (1/2") drawer bottom recess
Item No. Box List Pair List Pair Full Box
100 pr $5.28 $4.44
• Used to minimize sub front splitting
• Captive right device and self-aligning left device
• Self-adjusting drawer length tolerance
• Zinc die-cast with synthetic, spring-loaded release levers
• Minimum inside drawer width 124 (4-7/8")
• Height adjustment +3 (1/8")
• Minimum sub front thickness 16 (5/8")
• Designed for 13 (1/2") drawer bottom recess
Item No. Box List Pair List Pair Full Box
300 pr $6.16 $5.16
• Captive right device and self-aligning left device
• Self-adjusting drawer length tolerance
• Zinc die-cast with synthetic, spring-loaded release levers
• Minimum inside drawer width 124 (4-7/8")
• Height adjustment +3 (1/8")
Item No. Box List Pair List Pair Full Box
100 pr $4.04 $3.84
Standard
Vertical Mount Vertical Mount
Depth Adjustable Narrow Drawer - Vertical Mount
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
SLIDES
800.533.0533 2021 1946 420 Prices subject to change without notice.
