Bottom Mount Drawer Application
Description
• Use 563H, 563. (SHORT) or 563F series in 15", 18" and 21" lengths
• Face frame or panel cabinets
• Application is possible with any TANDEM 563 locking device
• 13 (1/2") to 19 (3/4") drawer thickness
• 100 lb. load capacity
3 (1/8")
X
67 (2-5/8") 9 (11/32")
Y Z
9 (11/32")
Item No. Runner
Length
Min. Inside
Cabinet Depth X Y Z
457 (18") 480 (18-29/32") 358 (14-3/32") 12 (15/32") 19 (3/4")
533 (21") 557 (21-15/16") 358 (14-3/32") 12 (15/32") 19 (3/4")
381 (15") 404 (15-29/32") 319 (12-9/16") 12 (15/32") 19 (3/4")
457 (18") 480 (18-29/32") 378 (14-7/8") 12 (15/32") 19 (3/4")
533 (21") 557 (21-15/16") 448 (17-5/8") 12 (15/32") 19 (3/4")
381 (15") 404 (15-29/32") 319 (12-9/16") 15.5 (5/8") 22.5 (7/8")
457 (18") 480 (18-29/32") 378 (14-7/8") 15.5 (5/8") 22.5 (7/8")
533 (21") 557 (21-15/16") 448 (17-5/8") 15.5 (5/8") 22.5 (7/8")
Runner mounting specifications
Top view
Item No.
Drawer
Length
Maximum Drawer
Material Thickness
For Overall
Cabinet Depth List Pair
457 (18")
16 (5/8")
533 (21") $50.68
533 (21") 610 (24") $52.30
381 (15") 457 (18") $54.74
457 (18") 533 (21") $53.78
533 (21") 610 (24") $55.48
381 (15")
19 (3/4")
457 (18") $50.28
457 (18") 533 (21") $49.00
533 (21") 610 (24") $50.40
