Step 4 — Cut gear racks to length
gear rack length
563x2290B10
271
(10-21/32")
563x3050B
331
(13-1/32")
563x3810B
407
(16-1/32")
563x4570B
483
(19-1/32")
563x5330B
560
(22-1/16")
Step 7 — Install linkage rod assembly
Close drawer runners
Slide linkage rod assembly left onto left pinion
Slide right pinion adapter onto right pinion
Step 3 — Install gear racks
Insert locating tabs into cut-outs on bottom of runners
Slide backward to lock into place
Step 1 — Attach left and right pinion housings
Insert locating pins into TANDEM runner
Press orange locking clips to lock into place
Step 5 — Cut linkage rod to length
Step 8 — Install locking clips
Install locking clips on both adapters
Installation instructions
Step 2 — Slide gear racks into pinion housings
Step 6 — Press pinion adaptors into linkage rod
click
click
The rear bracket moves to
accommodate up to
686
(27")
length TANDEM runners
opening width -
298
(11-23/32")
linkage rod
pinion adapter
pinion adapter
gear rack with locating tabs
gear rack length
linkage rod assembly
1
2
1
2
1
2
3
locking clip
Linkage rod length equals opening width minus
298
(11-23/32")
