COMPACT CLIP BLUMOTION Soft-Close
Pre-mounted screw
Cam height adjustment
Hinge-To-Door Attachment
Hinge Cup Centerpoint
Three-Dimensional Cam Adjustment
Mounting Plate Attachment
Hinges Per Door
BLUMOTION deactivation
For small or light doors, BLUMOTION can
be deactivated on one hinge. COMPACT
CLIP comes in the activated position,
markedwith "|". The deactivated position
is marked with "0". Door must be closed
once for the deactivation to complete.
COMPACT CLIP comes
pre-attached to the
mounting plate
with a pre-mounted screw
allowing for doors to be removed and
reattached quickly, and tool free.
COMPACT CLIP hinge comes
with a pre-mounted screw for
quick, easy screw head visibility
and improved accuracy.
COMPACT CLIP hinges are
interchangeable with all
current COMPACT BLUMOTION
and COMPACT hinges.
Hinge attachment
Step 1:
Slide hinge onto CLIP plate
until it clips in place.
Hinge removal
Step 1:
Locate CLIP release
lever on back of hinge (A), press
down to release (B).
Hinge removal
Step 2:
While CLIP lever is
released, pull forward on hinge/
door to remove from cabinet.
Allows for maximum adjustment
range without centering in an
elongated hole.
All adjustments now have
markings stamped on the
hingenear their corresponding
screw head.
Side adjustment
Height adjustment
Depth adjustment
B30C series
Rotate front cam screw to increase or
decrease door overlay (±1/16")
Rotate this cam screw to increase or
decrease the height (±5/64")
Rotate this cam screw to adjust door gap
(+3/32", -1/32")
wraparound/edge mount
Use #6 wood screws
wraparound
Pre-attached dowels installed with Blum
MINIPRESS or COMPACT insertion ram
Press-in
Screw-on
B31C series
Hinge cup centerpoint and
MINIPRESS setback position
is 20.5 (13/16") for COMPACT
CLIP hinges.
NOTE:
Maximum door thickness 3/4"
This chart can serve as a guide for
determining thenumber of hinges
per door. Note that door weight
can also determine the number
of hinges required.
Important:
Distance between the top and
bottom hinges must be greater
than the width of the door.
