Charles McMurray Co. 2021 Catalog

229c / 1590

Boring Pattern
NOTE:
Maximum door
thickness 3/4"
Minimum Reveal
minimum reveal
3/4" door = 7/32"
based on square
edge doors
Features
• Two-piece wrap-around hinge with CLIP tecnology
• 1/2" cup depth
• Less minimum reveal
• Three-dimensional cam adjust
• Pre-mounted wood screw
• Press-in hinges must be inserted with knock-in tool or
COMPACT insertion ram
BLUMOTION Soft-Close
• BLUMOTION soft-close integrated into the hinge cup
• Deactivation switch for small/light doors
• Overload safety feature
250 per box. Sold per each.
BLUMOTION Soft-Close
Item No. Overlay Mounting List Ea.
List Ea.
100
List Ea.
250
Wrap-Around
1" Press-in $9.88 $9.30 $8.32
1-1/4" Press-in $9.88 $9.30 $8.32
1-3/8" Press-in $9.88 $9.30 $8.32
1-1/2" Press-in $9.88 $9.30 $8.32
COMPACT CLIP BLUMOTION 31C3 - 110° Opening
Two-Piece Hinge, Full Overlay
Accessories
Item No. Description List Ea.
B38C315B3.1 Angle Restriction Clip (86°) $0.82
B38C355B9 Hinge Cup Spacer $4.46
Blank Covercap $0.96
Ram $83.90
Wrap-Around
Adjustment
NOTE: COMPACT BLUMOTION comes in the activated position, marked
with a "|". The deactivated position is marked with an "0".
Dimensions
Adjustments
Depth +3/32", -1/32"
Height ±5/64"
Side ±1/16"
COMPACT CLIP Accessories...pg. 229d
