Screw-On Wing Plate Face Frame Adapter Plate
BLUMOTION per Door
BLUMOTION
hinges
BLUMOTION 971A for doors
Features
• For use with straight-arm hinge and 0 mm mounting plate only
• Nickel-plated steel & gray nylon
• Adjustable to various door sizes and weights (+3/-7 mm range)
• Installed onto hinge side-panel
• Same quality of motion as in drawer systems w/BLUMOTION
• Designed for use with Blum euro hinges
37 mm set-back, 32 mm apart. Use #6 x 5/8"
wood screws. 25 each per box. Sold per each.
Item No. Height List Ea.
0 mm $9.06
9.5mm setback, 32mmapart. Use #6 x 5/8" wood
screws. 25 each per box. Sold per each.
Item No. Height List Ea.
0 mm $9.06
0 mm BLUMOTION
Application
For all hinges with a straight hinge
arm and a 0 mm mounting plate.
NOTE: 95° thick door hinge re-
quires 3 mm height BLUMOTION
(nonstock).
37
32
9.5
32
25
• For optiumum BLUMOTION effect, install onto the
hinge side panel, centered between the two hinges.
• Tall or heavy doors may require an addition
BLUMOTION between the hinges.
• Trial application recommended.
