Features
• Designed for frameless or face frame (blocked out) cabinet applications
• Works with CLIP top & CLIP free-swing hinges and with CLIP top
BLUMOTION using TIP-ON
• Can be bored into the side panel or used with an adjustable adapter plate
• Easy depth adjustment when used with an adapter plate
• Works for both overlay and inset applications
Benefits
• Quick and easy installation
• Increased design options
• Adjustment allows a perfect installation every time
• Requires minimal force to open and close
TIP-ON for doors for Blum Euro Hinges
For doors that open with a simple touch
Easy opening, secure closing
Installation position
Optimal opening support is achieved if the TIP-ON unit
is attached exactly where the handle would be.
The fixing position can deviate ±12" in height and up to a
quarter of the cabinet width in terms of width.
The TIP-ON unit can be bored into
the cabinet end panel.
The TIP-ON unit can also be attached to the cabi-
net interior using adapter plates.
In-line adapter plate Wing adapter plate
NOTES: Factory setting of door gap is 2 mm.
Minimum gap of 3 mm with a screw-on catch plate and 2.5 mm with a self-adhesive catch plate.
