Item No. List Ea.
CMT333-03 $711.80
Universal Hinge Boring System
Includes:
1 Universal Modular Base
1 Blum Boring Head(same pattern as Salice)
1 35 mm Bit
• 3 spindle-heads allow you to bore holes for all popular hinge
brands
• The universal modular base supports the installation of
different boring heads
• Use with hand-held drill or drill press
• Ground aircraft aluminium provides anti-rust parts
• Max 5,000 RPM
• 6 radial anti-friction bearings
Manual Boring Template
For Hinges and Mounting Plates
• For installing Blum hinges with INSERTA or EXPANDO hinges
• For boring Ø8 mm dowel holes after Ø35 mm hole is bored
• Wedge used for the bore distance locator
• Can accommodate all special bore distances (i.e. 3.5, 4.5, etc.)
• Also bores 5 mm holes for system screw mounting plates
• Includes drill stop collar to pilot bore 2.5 mm for screw-on plates
• Order bits separately 2.5 mm and 5 mm)
Item No. List Ea.
$93.12
• If mounting plates are standard, multiple templates can
be attached to a wooden strip
• Can be used to transfer measurements from door to cabinet
• Use with CLIP mounting plates on overlay applications
on frameless cabinets
• For wing mounting plates (37 mm setback) and in-line
mounting plates (20 mm setback)
• Simple location of mounting plate screw positions
• Pilot bore Ø2.5 mm holes for wood screws
Item No. List Ea.
$30.50
• For precisely drilling the Blum hinge pattern
• Driven by an electric hand drill or cordless drill (18v or higher)
• Variable drilling distance (from 2 to 8 mm)
• Clamps to various door thicknesses up to 40 mm (1-9/16")
• Includes drill bits, (pre-installed) and 2 torx driver bits
Item No. List Ea.
$818.10
Insertion Rams
For Hinge Installation
Item No. For Hinges List Ea.
107, 110, 120 $155.46
Compact Hinges $83.90
*Not for wide angle hinges or specialty hinges. Can be used
with 95° and 100° by adjusting ball plungers.
Mounting Plate Template
EcoDrill for Hinge Boring
5mm
holes
cursor
Anthony's
Hinge Jig
handle
5mm pins
side view
Use for locating the centerline for a hinge. Mounts easily into 5mm
holes. Use the cursor to draw a centerline. If the cabinets don't have
5mm holes, use the pins and align them along the edge of the cabinet,
drill with a 5mm driver bit in the drill guide and repeat the steps for
finding the centerline.
Item No. List Ea.
$15.30
Mounts easily into 5mm
holes. Use the cursor to
draw a centerline.
