Charles McMurray Co. 2021 Catalog

240 / 1590

In-Line Adapter Plate
For Standard Doors
Adapter plates attach with #6 x 5/8" wood screws (not included). Adjustable door gap (factory
setting 2mm). For face frame applications, blocking out may be required.
Wing Adapter Plate
For Large Doors
50 each per box. Sold per each.
Item No. Finish
List
Ea.
List Ea.
50
Black $3.64 $3.02
Gray* $3.46 $2.86
Nickel $5.96 $4.94
White $3.46 $2.86
*250 per box. Price break at 250.
50 each per box. Sold per each.
Item No. Finish List Ea.
List Ea.
50
Gray $2.14 $1.80
Application Setback
Overlay 20
Inset 22 + door thickness
Application Setback
Overlay 37
Inset 39 + door thickness
TIP-ON for doors for Blum Euro Hinges
Adapter Plates
In-Line Adapter Plate
For Large Doors
Application Setback
Overlay 20
Inset 22 + door thickness
• Two-piece, screw-on baseplate
• 20 mm setback, 17 mm apart
• Door gap factory setting 2 mm
• Black, gray, nickel or white nylon
• Two-piece, screw-on baseplate
• 20 mm setback, 32 mm apart
• Door gap factory setting 2 mm
• Black, gray, nickel or white nylon
• One-piece, screw-on wing baseplate
• 37 mm setback, 32 mm apart
• Door gap factory setting 2 mm
• Gray nylon
50 each per box. Sold per each.
Item No. Finish List Ea.
List Ea.
50
Black $3.64 $3.02
Gray* $3.44 $2.84
Nickel $5.96 $4.94
White $3.38 $2.80
*250 per box. Price break at 250.
NOTES: For face frame applications, blocking out may be required.
Recommended screw: #6 x 5/8" 1C)
