Charles McMurray Co. 2021 Catalog

239 / 1590

Mounting Plate Template Boring Template for TIP-ON
TIP-ON for doors for Blum Euro Hinges
TIP-ON sets work for both overlay and inset applications. Adjustment range +4 mm to -1
mm. Can be bored into the panel or used with an adapter plate.
Overlay
Inset
Overlay
Inset
50 each per box. Sold per each.
Item No. Finish List Ea.
List Ea.
50
Black $12.64 $10.72
Gray $12.64 $10.72
White $12.64 $10.72
50 each per box. Sold per each.
Item No. Finish List Ea.
List Ea.
50
Black $15.82 $13.42
Gray $15.82 $13.42
White $15.82 $13.42
Simple location of
mounting plate screw
positions. If mounting
plates are standard,
multiple templates can
be attached to awooden
strip. Pilot bores Ø2.5
mm holes for wood
screws.
Item No. List Ea.
$30.50
Allows pre-boring of
TIP-ON for doors. Ø10
mm drill bushing for
edge boring. Includes
10 mm stop collar.
Universal bores left and
right side of cabinet.
Bit not included (order FL28100393)
Item No. List Ea.
$68.20
Templates
For Free-Swinging Hinges
STANDARD
For Door Heights Less Than 48"
For Free-Swinging Hinges
LARGE
For Door Heights Greater Than 48"
For Soft-Close
& Self-Close Hinges
50 each per box. Sold per each.
Item No. Finish List Ea.
List Ea.
50
Black $13.46 $11.42
Gray $13.20 $11.22
White $13.46 $11.42
Nylon mechanismwith bumper tip. For doors
greater than 10" width.
Includes self-adhesive and screw-on catch
plates. Nylon mechanism with magnet tip.
Includes self-adhesive and screw-on catch
plates. Nylon mechanism with magnet tip.
Overlay
Inset
screw-on
catch plate
self-adhesive
catch plate
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
CABINET HINGES
800.533.0533 2021 1946 239 Prices subject to change without notice.
