• For marking and pre-boring of wing or in-line mounting plates,
BLUMOTION and TIP-ON adapter plates, and cabinet profiles
• Can be used for pre-boring AVENTOS locating pins
• Calibrated scale with preset positions for common applications
Set includes:
Universal individual template
Ø2.5 mm and Ø5 mm stop collars
Universal Individual Template
PlateMate Boring Template
For Face Frame Adapter Plates
• Boring template for all Blum face frame adapter plates.
• Clamps to the frame with cam lever
• Adjustment knob accommodates frame thickness of 5/8" to 1"
• Spacer screws permit quick use without measuring
• Includes 2.5 mm pilot bit and drill extension
Item No. List Ea.
$223.76
Item No. Description List Ea.
Template $219.90
5 mm Bit $20.74
3/32" Bit (2.5 mm) $3.74
adjustable
M4 x 25 mm
spacer screws included
• Accurate hinge positioning with built-in indexing tabs
• Repeatable results with built-in measuring scales
• Reliable drilling with bit guide and stop collar
• Adjustable cams ensure proper hinge offset
• Durable carbide-tipped drill bit included
• Hinge offset 3 mm, 4 mm, 5 mm, 6 mm
• Hinge offset from door end 2" to unlimited
Includes
(1) jig base with index cams (1) 35 mm carbide-tipped drill bit
(1) drill guide (1) stop collar with Hex wrench
Item No. List Ea.
$66.08
Concealed Hinge Jig
QUICKFIX Template for Hinges & Plates
• Locates/matches positions of hinges and plates on cabinets
and doors
• Transfers positions from door-to-cabinet and cabinet-to-door
• Adjustable stop for various door overlays
• For use with wing or in-line mounting plates
Item No. List Ea.
$282.18
Extension Ruler for Minipress
• 1250 mm (4')
Item No. List Ea.
$260.82
