Charles McMurray Co. 2021 Catalog

233 / 1590

Face Frame Adapter
In-Line Adapter
For standard applications For angled applications
BLUMOTION per Door
BLUMOTION 970A for CLIP top & CLIP Hinges
Features
• Soft closing feature for CLIP top & CLIP hinges
• Automatically adjusts to the closing force of the door
• Installed into the top and/or bottom panel or with adapter plates on hinge side
• Same quality of motion as in drawer systems w/BLUMOTION
• Designed for use with Blum Euro hinges
• Gray nylon
Item No. Box List Ea. List Ea. 50
250 $5.76 $4.78
• BLUMOTION 970A is designed for two BLUMOTION per door;
however, one may be enough depending on door size and weight
• Small or light doors may only require one BLUMOTION
• Trial application recommended
BLUMOTION 970A
Hinges
• 9.5 mm setback, 32 mm apart
• Nickel-plated steel
• Use #6x5/8" wood screws
• Can also be used in frameless cabinets
50 each per box, sold per each.
Item No. List Ea. List Ea. 50
$2.14 $1.78
• 20 mm setback, 32 mm apart
• Nickel-plated steel & gray nylon
• Two-piece design
• Use #6x5/8" wood screws
50 each per box, sold per each.
Item No. List Ea. List Ea. 50
$2.44 $1.98
BLUMOTION
Boring Distance Chart for BLUMOTION 970A Bullets
Standard applications
Blind corner applications
Overlay
boring distance
Twin
boring distance
Inset
boring distance
Inset with straight-arm
boring distance
Mounting
plate height
0 mm 32 0 mm 41 0 mm 50 18 mm 50
3 mm 35 3 mm 44 3 mm 53
6 mm 38 6 mm 47
9 mm 41 9 mm 50
Inset blind corner
boring distance
Overlay blind corner
boring distance
Mounting
plate height
0 mm 32
3 mm 51 3 mm 35
6 mm 38
application (app)
boring distance (X) in mm
ø10
50
min.
X
boring distance (X) in mm
mounting plate height
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
CABINET HINGES
800.533.0533 2021 1946 233 Prices subject to change without notice.
