Charles McMurray Co. 2021 Catalog

1238 / 1590

Residential-Duty Locksets
Door Prep: Crossbore 2-1/8", Edge Bore 1"
Backset: Adjustable to 2-3/8" or 2-3/4"
Door: 1-3/8" to 1-3/4"
Faceplate: 1" x 2-1/4", 1/4" radius corner
Strike: 2-1/4" full lip, 1/4" radius corner
Cylinder: SmartKey
Bolt: 1/2" throw
ANSI/BHMA: A156.2 Grade 3 (except 488)
ADA: Satisfies 4.13.9 ADA requirements (except 488)
Exterior Dimensions
Style A B C C (Entry)
Balboa 2-5/8" 4-7/32" 1-15/16" 2-13/32"
Balboa (BL) with SmartKey
Item No. Function Finishes Case List Ea.
Passage 11P 20 $48.60
15 20 $48.60
Privacy 11P 20 $51.60
15 20 $51.60
Entry 11P 20 $72.10
15 20 $72.10
Half Dummy 11P 20 $24.30
15 20 $24.30
*Specify left or right-hand door.
(except 488
dummy)
NOTES:
For latches and strikes see catalog page 1243.
Prices shown are Kwikset's List Prices from July 2022 Box Pack Price Guide.
Finishes
11P Venetian Bronze
15
Stocked KA4
