Charles McMurray Co. 2021 Catalog

1233 / 1590

Single Cylinder
Item No. Finish Case List Ea.
Satin Nickel 12 $74.50
Polished Chrome 12 $74.50
Matte Black 12 $78.10
Milan Series Deadbolts
Door Prep: Crossbore 2-1/8" or 1-1/2", Edge Bore 1"
Backset: 2-3/8" or 2-3/4" adjustable latch
Door: 1-3/8" to 1-3/4"
Cylinder: Smart Key
Faceplate: 1" x 2-1/4", 1/4" radius corner
Bolt: 1" throw
ANSI/BHMA: A156.36. Grade 2
ADA: Satisfies section 4.13.9 ADA requirements
Style A B C D
Exterior 2-17/32" 15/16" - 3/8"
Interior 2-17/32" 1-13/32" 1-11/16" 3/8"
Item No. Function Finishes Case List Ea.
Passage 15, 26 12 $71.40
514 12 $75.00
Privacy 15, 26 12 $74.70
514 12 $78.30
Entry 15 12 $124.30
514 12 $127.90
Half Dummy 15 20 $35.70
514 20 $37.50
Door Prep: Crossbore 2-1/8", Edge Bore 1"
Backset: Adjustable to 2-3/8" or 2-3/4"
Door: 1-3/8" to 1-3/4"
Cylinder: SmartKey, square spindle
Faceplate: 1" x 2-1/4", 1/4" radius corner
Strike: 1-1/8 x 2-3/4", 1/4" radius corner
Bolt: 1" throw steel
ANSI/BHMA: A156.36 Grade 2
Milan (MILRDT)
Passage
Privacy has a
push-button
interior
Entry
Exterior Dimensions
Style A B C C (Entry)
Milan 2-5/8" 4-5/32" 2-9/16" 2-3/8"
Stocked KD
NOTES:
For strikes see catalog page 1243.
Prices shown are Kwikset's List Prices from July 2022 Box Pack Price Guide.
Finishes
15
26 Polished Chrome
514 Matte Black
Interior has a
thumb-turn
(15) Polished Chrome (26)
Entry has a
push-button
interior
