Charles McMurray Co. 2021 Catalog

1230 / 1590

Active Exterior Trim Designs
Item No. Style Finishes List Ea.
SmartKey
Amador 15SMT $189.80
26SMT $189.80
514SMT $199.00
Belleview 15SMT $151.20
Dakota 11P-SMT $151.20
15SMT $151.20
Pin & Tumbler
Dakota 11P $146.20
15 $146.20
Exterior Handle Only (no deadbolt)
Item No. Style Finishes List Ea.
Amador 15 $156.80
514 $166.00
Belleview 15 $113.20
Dakota 15 $113.20
687/699 Series Standard-Duty Handlesets
Active Interior Trim Designs for 687 Series
Item No. Style Finishes List Ea.
Aliso Knob 15 $53.70
Balboa Lever 11P, 15 $65.60
Breton Lever 15, 26, 514 $65.60
Casey Lever 15, 26, 514 $65.60
Cove Knob 11P, 15 $53.70
Dorian Lever 11P, 15 $65.60
KW604HFLSQT Halifax Lever 15, 514 $71.50
Ladera Lever 15, 26, 514 $65.60
KW604LRLSQT* Ladera Lever 15, 26, 514 $65.60
Polo Knob 11P, 15, 26 $53.70
Tylo Knob 3 $53.70
Tustin Lever 11P, 15 $71.50
*Specify left or right-hand door.
Dakota
Door Prep: Deadbolt: Crossbore 2-1/8" or 1-1/2", Edge Bore 1".
Handle: Crossbore 2-1/8", Edge Bore 1"
Backset: Deadbolt: 2-3/8" or 2-3/4"
Handle: 2-3/8" or 2-3/4"
Door Thickness: 1-3/4"
Cylinder: 5-pin
Faceplates: 1" x 2-1/4", 1/4" radius corner
Strikes: Deadbolt: 1" x 2-1/4", 1/4" radius corner
Handle: 2-1/4" full lip, 1/4" radius corner
Bolts: Deadbolt: 1" throw
Handle: 1/2" throw
ANSI/BHMA: A156.5 Grade 3 deadbolt
Style A B
Amador 9-11/16" 17-15/32"
Belleview 8-13/32" 18-1/16"
Dakota 8-13/32" 17-3/16"
Belleview Amador
Prices shown are Kwikset's List Prices
from July 2022 Box Pack Price Guide.
Finishes
3 Polished Brass 26 Polished Chrome
11P Venetian Bronze 514 Matte Black
15
Order exterior and interior trims separately.
09/22
