800 Series Heavy-Duty Handlesets
Door Prep:
Deadbolt Cross Bore: 2-1/8" or 1-1/2"
Handleset Cross Bore: 2-1/8"
Edge Bore:1"
Latch Face: 1" x 2-1/4"
Backset
Deadbolt: Adjustable 2-3/8" or 2-3/4"
Handle: Adjustable 2-3/8" or 2-3/4"
Door Thickness: 1-3/4", not designed for use on 1-3/8" doors
Cylinder:
SmartKey
Faceplate:
1" x 2-1/4", radius corner
Strikes
Deadbolt: 1-1/4" x 3-5/8", 1/4" radius corner
Handle: 2-1/4" full lip 1/4" radius corner
Bolts
Deadbolt: Brass bolt, Full 1" throw, Titanium alloy roller pin
Handle: 1/2" throw, nickel plated
ANSI/BHMA:
Deadbolt is Grade 1.
Lifetime warranty on finish & mechanical
Arlington
®
11P
Ashfield
™
15
Austin
11P
Avalon
™
514
Chelsea
®
LT3
Hawthorne
™
15
Shelburne™
11P
Tavaris
™
26
Style
A
B
C
D
E
Arlington*
2-1/2"
5-1/2"
11"
19-1/16"
15"
Ashfield
2-31/32"
5-1/2"
8-13/32" 17-3/4" 14-7/16"
Austin*
3-5/32"
5-1/2"
8-13/32"
9-1/8"
9-11/16"
18-27/64" 13-7/8"
Avalon*
2-7/8"
5-1/2"
8-13/32" 18-5/32" 12-5/8"
Chelsea*
2-3/16"
5-1/2"
9-11/16" 18-1/2"
13"
Hawthorne* 2-7/8"
5-1/2"
8-13/32" 17-7/16" 13-3/8"
Shelburne
2-7/8"
5-1/2"
8-13/32" 18-1/4"
12-5/8"
Tavaris*
2-1/2"
5-1/2"
8-27/64"
18"
12-3/4"
See next page for stock finishes and interior trims.
Style
A
B
C
D
E
F
Arlington
2-3/4" 3-3/4" 2-3/4" 5-1/2" 1-3/4" 3-1/2"
Ashfield
2-3/4"
4"
2-3/4" 4-3/4" 1-3/4"
3"
Austin
2-3/4" 3-7/8" 2-3/4" 4-5/8" 2-1/4" 3-3/16"
Avalon
2-3/4" 4-1/2" 2-3/4" 4-3/8"
2" 3-1/8"
Chelsea
2-3/4"
4"
2-3/4"
4”
2"
3"
Hawthorne 2-1/2" 2-3/4" 2-1/2" 5-1/8" 1-3/4" 3-1/2"
Shelburne
2-1/2" 4-1/2" 2-1/2" 4-3/4"
2"
3-1/2"
Tavaris
2-1/4" 4-1/4" 2-3/4" 4-1/2" 2-1/8" 3-1/4"
Trim Measurements
A
C
B
D
F
E
A
E
F
B
Two-Piece
One-Piece
*Also sold with handle only (no deadbolt). See page 1227.
