Charles McMurray Co. 2021 Catalog

1234 / 1590

Lisbon (LSLSQT)
Passage (15)
Privacy (514)
Privacy has a push-
button interior
Entry (11P)
Entry has a push-
button interior
Dummy (15)
(except 157
dummy)
Residential-Duty Locksets
Door Prep: Crossbore 2-1/8", Edge Bore 1"
Backset: Adjustable to 2-3/8" or 2-3/4"
Door: 1-3/8" to 1-3/4"
Faceplate: 1" x 2-1/4", 1/4" radius corner
Strike: 2-1/4" full lip, 1/4" radius corner
Cylinder: SmartKey, square spindle
Bolt: 1/2" throw
ANSI/BHMA: Grade 2 (except 157)
ADA: Satifies 4.13.9 ADA requirements (except 157)
Exterior Dimensions
Style A B C C (entry)
Lisbon 2-5/8" 4-5/32" 2-9/16" 2-3/8"
Montreal 2-5/8" 4-1/4" 2-5/8" 2-11/16"
Item No. Function Finishes Case List Ea.
Passage 11P, 15 12 $71.40
514 12 $75.00
Privacy 11P, 15 12 $74.70
514 12 $78.30
Entry 11P, 15 12 $124.30
514 12 $127.90
Half Dummy 11P, 15 20 $35.70
514 20 $37.50
Montreal (MRLSQT)
Passage (15)
Privacy (15)
Privacy has a push-
button interior
Entry (11P)
Entry has a push-
button interior
Dummy (15)
No. Function Finishes Case List Ea.
Passage 11P, 15 12 $71.40
514 12 $75.00
Privacy 11P, 15 12 $74.70
514 12 $78.30
Entry 11P, 15 12 $124.30
514 12 $127.90
Half Dummy 11P, 15 20 $35.70
514 20 $37.50
NOTES:
Privacy and entry have push-button on interior.
For strikes see catalog page 1243.
Prices shown are Kwikset's List Prices from July 2022 Box Pack Price Guide.
Finishes
11P Venetian Bronze
15
514 Matte Black
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
DOOR LOCKS & HARDWARE
800.533.0533 2021 1946 1234 Prices subject to change without notice.
