Charles McMurray Co. 2021 Catalog

1237 / 1590

Residential-Duty Locksets
Door Prep: Crossbore 2-1/8", Edge Bore 1"
Backset: Adjustable to 2-3/8" or 2-3/4"
Door: 1-3/8" to 1-3/4"
Cylinder: SmartKey
Faceplate: 1" x 2-1/4", 1/4" radius corner
Strike: 2-1/4" full lip, 1/4" radius corner
Bolt: 1/2" throw, nickel plated
ANSI Standard: A156.2 Grade 2
ADA: Functions 720 & 788 satisfy section 4.13.9 ADA requirements
Exterior Dimensions
Style A B C C (entry)
Pembroke 2-5/8" 4-7/32" 2-23/32" 2-23/32"
Tustin 2-5/8" 4-1/4" 2-3/32" 2-19/32"
(Passage &
dummy
functions only)
Pembroke (PML)
Brass Plated Zinc
Item No. Function Finishes Case List Ea.
Passage 11P, 15 12 $71.40
Privacy 11P, 15 12 $74.70
Entry 11P, 15 12 $124.30
Half Dummy 11P, 15 20 $35.70
*Specify left or right-hand door.
Tustin (TNL)
Item No. Function Finishes Case List Ea.
Passage 11P, 15, 26 20 $60.60
514 20 $64.20
Privacy 11P, 15, 26 20 $63.90
514 20 $67.50
Entry 11P, 15, 26 20 $89.50
514 20 $93.10
Half Dummy 11P, 26 20 $30.30
514 20 $32.10
*Specify left or right-hand door.
NOTES:
For latches and strikes see catalog page 1243.
Prices shown are Kwikset's List Prices from July 2022 Box Pack Price Guide.
Finishes
11P Venetian Bronze 26 Polished Chrome
15 514 Matte Black
