Charles McMurray Co. 2021 Catalog

1239a / 1590

Exterior Dimensions
Style A B C C (Entry)
Ladera 2-5/8" 4-3/16" 1-7/8" 2-7/16"
(200 & 420)
Ladera (LRLSQT)
Item No. Function Finishes Case List Ea.
Passage 15**, 26 12 $48.60
514** 12 $51.60
Privacy 15**, 26 12 $51.60
514* 12 $54.60
Half Dummy 15**, 26 12 $24.30
514 12 $25.80
Entry With SmartKey
Entry 15-SMT**
26-SMT 12 $72.10
514-SMT** 12 $75.10
*Specify left or right-hand door.
**Features Microban® antimicrobial finish.
Passage (200)
Privacy (300)
Dummy (488)
Entry w/SmartKey
(405)
NOTES:
Privacy and entry have turn-button on interior.
For latches and strikes see catalog page 1243.
Prices shown are Kwikset's List Prices from July 2022
Box Pack Price Guide.
Door Prep: Crossbore 2-1/8", Edge Bore 1"
Backset: Adjustable to 2-3/8" or 2-3/4"
Door: 1-3/8" to 1-3/4"
Faceplate: 1" x 2-1/4"
Strike: 2-1/4" full lip round corner, other options avail.
Cylinder: SmartKey
Bolt: 1/2" throw
ANSI/BHMA: Grade 3 (except 488)
ADA: Functions 200 & 420 meet ANSI A117.1 and ADA
requirements
10/22
