Charles McMurray Co. 2021 Catalog

1239 / 1590

(Passage
function only)
Dorian (DNL)
Residential-Duty Locksets
Item No. Function Finishes Case List Ea.
Passage 11P, 15 20 $48.60
Privacy 11P, 15 20 $51.60
Half Dummy 11P, 15 20 $24.30
Entry w/SmartKey
Entry 11P-SMT, 15SMT 20 $72.10
Entry w/Pin & Tumbler
Entry 11P, 15 20 $67.10
Door Prep: Crossbore 2-1/8", Edge Bore 1"
Backset: Adjustable to 2-3/8" or 2-3/4"
Door: 1-3/8" to 1-3/4"
Faceplate: 1" x 2-1/4", 1/4" radius corner
Strike: 2-1/4" full lip, 1/4" radius corner
Cylinder: SmartKey or 5-pin
Bolt: 1/2" throw
ANSI/BHMA: A156.2 Grade 3 (except 488)
ADA: Dorian 200 functions satisfies section
4.13.9 ADA requirements
Ladera satisfies 4.13.9 ADA requirements (except 488)
Exterior Dimensions
Style A B C C (Entry)
Dorian 2-5/8" 3-3/4" 2-1/8" 2-11/16"
Ladera 2-5/8" 4-3/16" 1-7/8" 2-7/16"
NOTES:
For latches and strikes see catalog page 1243.
Prices shown are Kwikset's List Prices from July 2022
Box Pack Price Guide.
Finishes
11P Venetian Bronze 26 Polished Chrome
15 514 Matte Black
Stocked KA4
(except 488
dummy)
Ladera (LRLRDT)
Item No. Function Finishes Case List Ea.
Passage 15, 26, 514 20 $48.60
Privacy 15, 26, 514 20 $51.60
Half Dummy 15, 26, 514 20 $24.30
Entry With SmartKey
Entry 15-SMT 20 $72.10
514-SMT 20 $75.10
*Specify left or right-hand door.
Passage (200)
Privacy (300)
Dummy (488)
Entry w/SmartKey
(405)
NOTES:
Privacy and entry have turn-button on interior.
For latches and strikes see catalog page 1243.
Prices shown are Kwikset's List Prices from July 2022
Box Pack Price Guide.
