Charles McMurray Co. 2021 Catalog

1236 / 1590

Residential-Duty Locksets
Exterior Dimensions
Style A B C C (entry)
Commonwealth 2-5/8" 4-7/32" 2-7/16" 2-7/16"
Commonwealth (CHL)
Brass Plated Zinc
Item No. Function Finishes Case List Ea.
Passage 11P, 15 12 $71.40
Privacy 11P, 15 12 $74.70
Entry 11P, 15 12 $124.30
Half Dummy 11P, 15 20 $35.70
*Specify left or right-hand door.
(Passage &
dummy
functions only)
Door Prep: Crossbore 2-1/8", Edge Bore 1"
Backset: Adjustable to 2-3/8" or 2-3/4"
Door: 1-3/8" to 1-3/4"
Cylinder: SmartKey
Faceplate: 1" x 2-1/4", 1/4" radius corner
Strike: 2-1/4" full lip, 1/4" radius corner
Bolt: 1/2" throw, nickel plated
ANSI Standard: A156.2 Grade 2
ADA: Functions 720 & 788 satisfy section 4.13.9 ADA requirements
Finishes
11P Venetian Bronze
15
NOTES:
For latches and strikes see catalog page 1243.
Prices shown are Kwikset's List Prices from July 2022 Box Pack Price Guide.
