Charles McMurray Co. 2023 Catalog

432 / 1645

32
(1-1/4")
9.5 (3/8")
57
(2-1/4")
• For use with face frame or panel cabinets
• Can be mounted to side or bottom of cabinet opening
• Pre-bore with Ø2.5 mm drill bit
NOTE: Blum distance bumpers provide a travel of 3 (1/8")
Item No. List Ea.
List Ea.
50
$15.18 $12.06
SERVO-DRIVE Mounting Components
Vertical Application
Vertical Aluminum Profile
31-1/2" cable included. Profile can be cut
to size.
Item No. Length List Ea.
720 (28-3/8") $172.40
Adapter Set f/Vertical Profile - Top & Bottom
For use with horizontal stretcher rail.
Complete specifications can be
downloaded at
Set No. List Set
$20.84
Top Bracket w/Adapter
Use euro screws.
Item No. List Ea.
$109.00
Bottom Bracket
for 2 drive units
Universal cable is included, 800 mm
(31-1/2"). Use MCFPT586 screws.
Item No. List Ea.
$75.78
Distance Bumper
Drawer Front
For drawer heights 305 mm
(12") or less: two distance
bumpers are required. Center
bumpers vertically left/right side
of drawer front.
For drawer heights 305 mm
(12") and higher: four distance
bumpers are required.
Note: Distance bumpers provide
a travel of 3 mm (1/8").
Item No. List Ea.
$4.78
drawer front height <305
drawer front height >305
Distance Bumper
Cabinet Side - Side or Bottom Mount
Lateral Stabilizer Bracket
• Used for stabilizing wide drawers and/or tall drawer fronts
• Reinforces the connection between the drawer bottom
& the front
• One required per drawer, center on drawer bottom
Item No. Finish List Ea.
Gray $6.50
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
SLIDES
800.533.0533 432 Prices subject to change without notice.
