Charles McMurray Co. 2023 Catalog

438 / 1645

Set No.
Nominal
Length
Actual
Length
List Per Set
Gray
(SOS-GR)
White
(SOS-WH)
Stainless
(SOI-SS)
18" 17-11/16" $159.74 $159.74 $212.52
20" 19-11/16" $159.20 $159.20 $213.78
22" 21-5/8" $170.00 $170.00 $224.56
*Specify Gray (SOS-GR), White (SOS-WH) or Stainless Steel (SOI-SS)
Orion Gray Silk White Stainless Steel LEGRABOX - N Height (2-5/8") in
Load Rating of 125 lbs. based on ANSI/BHMA standards
06/23
Drawer Height: 66.5mm (2-5/8").
Minimum Opening Height: 80mm based on 3mm (1/8") clearance.
Minimum depth = actual profile length +3mm (1/8").
Standard Drawers
Optional TIP-ON BLUMOTION Units
for Touch-to-Open/Soft-Close
Set No.
For
Length List Set
For up to 44 lbs.
BT60L7140 11" only $49.88
BT60L7340 14-22" $49.88
For 44-88 lbs.
BT60L7540 14-22" $49.88
For 88-155 lbs.
BT60L7570 18-24" $49.88
NOTE: Interior roll-out not available in N height.
Sold as a set: (Specify color when ordering)
1 pair Drawer Profiles w/Cover Caps
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
2 each EXPANDO Front Fixing Brackets
(All installation screws are included.)
Components
BZB7N000S (Set)
Rear Fixing Bracket
BZF7N70E2 (Set)
Front Fixing Bracket
B770N (Set) Drawer & Cabinet Profiles
For more information and accessories see page 443.
Item No. Description List Ea.
Fixing Brackets
Rear fixing bracket $4.70
BZF7N70E2 EXPANDO front fixing bracket $2.96
Includes left and right TIP-ON BLUMOTION units & triggers
and 2 synchronization adapters.
DOOR
HARDWARE
TOOLS FASTENERS SHOP &
FINISHING
ABRASIVES LACQUERS &
FINISHES
ADHESIVES FURNITURE
HARDWARE
EDGING &
DECOR.WOOD
SHELF &CLOSET
ORGANIZERSKITCH./BATH
LIGHTING SLIDES
DOORS &DRAWERS
LOCKS &CATCHES
AVENTOS &
LIFTS
CABINETHINGES
DECORATIVEHARDWARE
SLIDES
800.533.0533 438 Prices subject to change without notice.
