Charles McMurray Co. 2023 Catalog

440 / 1645

Item No. Description
Gray
(OGM)
White
(SWM)
Stainless
(INGL)
Accessories for Interior Drawer
Int. front fixing bracket $65.62 st $65.60 st $106.06 st
Front piece $55.42 ea $56.52 ea $131.94 ea
Cross Gallery Rail $25.50 ea $23.50 ea $89.20 ea
Fixing Brackets Gray (OGM) White (SWM)
Rear fixing bracket $6.16 pr $6.16 pr
BZF7C70E2 EXPANDO front fixing bracket $2.96 pr
*Specify color when ordering.
Orion Gray Silk White Stainless Steel LEGRABOX - C Height (7") in
Load Rating of 125 lbs. and 170 lbs. based on ANSI/BHMA standards
Kit No.
List Per Kit
Gray
(SOS-GR)
White
(SOS-WH)
Stainless
(SOI-SS)
$146.54 $145.62 $327.20
*Specify Gray (SOS-GR), White (SOS-WH) or Stainless Steel (SOI-SS)
Set No.
Nominal
Length
Actual
Length
List Per Set
Gray
(SOS-GR)
White
(SOS-WH)
Stainless
(SOI-SS)
125 lb. Load Rating
11" 10-5/8" $204.96 $204.96 $293.90
14" 13-3/4" $204.50 $204.50 $293.42
16" 15-3/4" $196.04 $196.04 $287.44
18" 17-11/16" $197.78 $197.78 $291.58
20" 19-11/16" $197.62 $197.62 $293.88
22" 21-5/8" $208.34 $208.34 $308.88
170 lb. Load Rating
20" 19-11/16" $214.30 $214.30 $310.56
22" 21-5/8" $225.02 $225.02 $325.58
24" 23-5/8" $255.62 $255.62 $367.76
*Specify Gray (SOS-GR), White (SOS-WH) or Stainless Steel (SOI-SS)
For TIP-ON
BLUMOTION
Units
(Touch-to-Open/
Soft-Close)
see page 443.
BZR7.1080U Cross Gallery Rail
1080 (42-1/2") (cut to size)
L=opening width minus 90 (3-1/2")
BZB7C000S (Set)
Rear Fixing Bracket
B770C/773C (Set)
Drawer & Cabinet Profiles
Standard Drawer Components Interior Roll-out Components
BZF7C70E2 (Set)
Front Fixing Bracket
BZI7.3C (Set)
Interior Front Fixing Bracket
1043 mm (41-1/16") cut-to-size
L=inside cabinet width minus 126 (5")
H: 96 mm
BZV7.1043C01
Front Piece
06/23
Interior Roll-out Drawers Standard Drawers
Drawer Height: 177mm (7").
Minimum Opening Height: 193mm (7-5/8") based on 3mm (1/8")
clearance.
Minimum depth = actual profile length +3mm (1/8").
Drawer Height: 177mm (7").
Minimum Opening Height: 191mm (7-1/2") based on 3mm (1/8")
clearance.
Minimum depth = actual profile length +3mm (1/8").
Sold as a set: (Specify color when ordering)
1 pair Drawer Profiles w/Cover Caps
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
2 each EXPANDO Front Fixing Brackets*
(All installation screws are included.)
*When building Interior Roll-out Drawers, use
Front Fixing Brackets included in LB-C-INT kit.
For Interior Roll-out Drawers
Use Standard Drawer Set + Interior Roll-out Kit
LB-C-INT (Specify color when ordering)
BZI7.3C (Set)
Interior Front Fixing Bracket
BZV7.1043C01 Front Piece
BZR7.1080U Cross Gallery Rail
(Required for interior roll-out.)
Kit includes:
1 set Interior Front Fixing Brackets
1 ea. Front Piece
(All installation screws are included.)
