BZI7.0M (Set)
Interior Front Fixing Bracket
BZB7M000S (Set)
Rear Fixing Bracket
BZF7M70E2 (Set)
Front Fixing Bracket B770M/773M (Set)
Drawer & Cabinet Profiles
Item No. Description
Gray
(OGM)
White
(SWM)
Stainless
(INGL)
Interior Drawer Parts
Int. front fixing bracket $49.86 st $53.02 st $69.28 st
Front piece $55.42 ea $56.52 st $131.94 ea
Fixing Brackets Gray (OGM) White (SWM)
Rear fixing bracket $4.70 pr $4.70 pr
BZF7M70E2 EXPANDO front fixing bracket $1.34 pr
*Specify color when ordering.
BZV7.1043C01
Front Piece
1043 mm (41-1/16") cut-to-size
L=inside cabinet width minus 126 (5")
H: 96 mm (sits flush with top of M height drawer)
For TIP-ON
BLUMOTION
Units
(Touch-to-Open/
Soft-Close)
see page 443.
Standard Drawer Components Interior Roll-out Components
06/23
Orion Gray Silk White Stainless Steel LEGRABOX - M Height (3-9/16") in
Load Rating of 125 lbs. and 170 lbs. based on ANSI/BHMA standards
Sold as a set: (Specify color when ordering)
1 pair Drawer Profiles w/Cover Caps
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
2 each EXPANDO Front Fixing Brackets*
(All installation screws are included.)
*When building Interior Roll-out Drawers, use
Front Fixing Brackets included in LB-M-INT kit.
For Interior Roll-out Drawers
Use Standard Drawer Set + Interior Roll-out Kit
LB-M-INT (Specify color when ordering)
Kit No.
List Per Kit
Gray
(SOS-GR)
White
(SOS-WH)
Stainless
(SOI-SS)
$105.28 $109.54 $201.22
*Specify Gray (SOS-GR), White (SOS-WH) or Stainless Steel (SOI-SS)
Interior Roll-out Drawers Standard Drawers
Drawer Height: 90.5 mm (3-9/16").
Minimum Opening Height: 106 mm (4-3/16") based on 3 mm (1/8")
clearance.
Minimum depth = actual profile length +3 mm (1/8").
Drawer Height: 90.5 mm (3-9/16").
Minimum Opening Height: 104 mm (4-1/16") based on 3 mm (1/8")
clearance.
Minimum depth = actual profile length +3 mm (1/8").
Set No.
Nominal
Length
Actual
Length
List Per Set
Gray
(SOS-GR)
White
(SOS-WH)
Stainless
(SOI-SS)
125 lb. Load Rating
11" 10-5/8" $162.26 $162.26 $211.46
14" 13-3/4" $161.78 $161.78 $210.98
16" 15-3/4" $155.58 $155.58 $206.58
18" 17-11/16" $156.84 $156.84 $209.66
20" 19-11/16" $157.24 $157.24 $211.84
22" 21-5/8" $167.40 $167.40 $223.28
170 lb. Load Rating
20" 19-11/16" $200.66 $162.34 $228.52
22" 21-5/8" $184.04 $184.04 $239.96
24" 23-5/8" $213.24 $213.24 $275.58
*Specify Gray (SOS-GR), White (SOS-WH) or Stainless Steel (SOI-SS)
BZI7.0M (Set)
Interior Front Fixing Bracket
BZV7.1043C01
Front Piece
(Required for interior roll-out.)
Kit includes:
1 set Interior Front Fixing Brackets
1 ea. Front Piece
(All installation screws are included.)
