Charles McMurray Co. 2023 Catalog

441 / 1645

Set No.
Nominal
Length
Actual
Length
List Per Set
Gray
(SOS-GR)
White
(SOS-WH)
Stainless
(SOI-SS)
125 lb. Load Rating
16" 15-3/4" $270.72 $270.72 $377.62
18" 17-11/16" $272.68 $272.68 $382.38
20" 19-11/16" $273.02 $273.02 $385.48
22" 21-5/8" $283.66 $283.66 $400.32
170 lb. Load Rating
20" 19-11/16" $289.70 $289.70 $402.18
22" 21-5/8" $300.34 $300.34 $417.02
*Specify Gray (SOS-GR), White (SOS-WH) or Stainless Steel (SOI-SS)
Orion Gray Silk White Stainless Steel LEGRABOX - F Height (9-1/2") in
Load Rating of 125 lbs. and 170 lbs. based on ANSI/BHMA standards
Item No. Description List Pr.
Fixing Brackets Gray
(OGM)
White
(SWM)
Rear fixing bracket $12.56 $12.56
BZF7C70E2 C EXPANDO front fixing brkt $2.96
BZF7M70E2 M EXPANDO front fixing brkt $1.34
*Specify color when ordering.
06/23
Drawer Height: 241mm (9-1/2").
Minimum Opening Height: 257mm (10-1/8") based on 3mm (1/8") clearance.
Minimum depth = actual profile length +3mm (1/8").
NOTE: Interior roll-out not available in F height.
Standard Drawers
Optional TIP-ON BLUMOTION Units
for Touch-to-Open/Soft-Close
Set No.
For
Length List Set
For up to 44 lbs.
BT60L7140 11" only $49.88
BT60L7340 14-22" $49.88
For 44-88 lbs.
BT60L7540 14-22" $49.88
For 88-155 lbs.
BT60L7570 18-24" $49.88
Sold as a set: (Specify color when ordering)
1 pair Drawer Profiles w/Cover Caps
1 pair Cabinet Profiles
1 pair Rear Fixing Brackets
2 each C EXPANDO Front Fixing Brackets
2 each M EXPANDO Front Fixing Brackets
(All installation screws are included.)
BZB7F000S (Set)
Rear Fixing Bracket
BZF7C70 (Set)
C Front Fixing Bracket
BZF7M70 (Set)
M Front Fixing Bracket
Components
B770F/773F (Set) Drawer & Cabinet Profiles
For more information and accessories see page 443.
Includes left and right TIP-ON BLUMOTION units & triggers
and 2 synchronization adapters.
DECORATIVE
HARDWARE
CABINET
HINGES
AVENTOS &
LIFTS
LOCKS & CATCHES
DOORS & DRAWERS
SLIDES
LIGHTING ORGANIZERS
KITCH./BATH
SHELF & CLOSET
EDGING & DECOR.WOOD
FURNITURE HARDWARE
ADHESIVES LACQUER &
FINISHES
ABRASIVES
SHOP & FINISHING
FASTENERS
TOOLS
DOOR
HARDWARE
SLIDES
800.533.0533 441 Prices subject to change without notice.
