D-Motion 2D/3D Undermount Slides
Series DS20
Soft-Close, Full Extension
100 lb. Load Rating
Slides include locking devices (2D-CLIP with screws), order 3D-CLIP
separately. Order slide screws and rear mounting brackets
separately. Sold per pair.
Item No. Length Box List Pair List Pair 6
12" 6 $35.70 $30.84
15" 6 $35.70 $30.84
18" 6 $35.58 $30.94
21" 6 $37.30 $32.42
Item No. Description Box List Price
Rear Mounting Bracket-Metal 100pr $1.02 pr
Rear Mounting Bracket-Plastic 90pr $1.19 pr
2D Locking Device 100pr $4.48 pr
3D Locking Device 100pr $4.50 pr
Screws for slides #7 x 5/8" FHPH 1c $8.24 bx
Screws for clips #6 x 1/2" TH 1c $11.48 bx
• Silent system guarantees smooth run without noise
• 2D adjustment: height 0-3 mm, side ±1.5 mm
• 3D adjustment: height 0-3 mm, side ±1.5 mm, depth 0-3.5 mm
• Maximum drawer thickness is 5/8"
• Zinc-plated
1. Slide
2. Locking Device
3. Rear Mounting
Bracket
Drawer length Slide Length
Internal Cabinet Depth
Maximum Minimum
305 (12") 317 (12-1/2") 369 (14-9/16") 326 (12-7/8")
381 (15") 394 (15-1/2") 446 (17-9/16") 403 (15-7/8")
457 (18") 470 (18-1/2") 522 (20-9/16") 479 (18-7/8")
533 (21") 546 (21-1/2") 598 (23-9/16") 555 (21-7/8")
LT = Internal
cabinet depth
Installation Dimensions Face Frame Cabinet (with rear bracket)
Installation Dimensions for Frameless Cabinet
Drawer length Slide Length Minimum Int. Cab. Depth
305 (12") 317 (12-1/2") 326 (12-7/8")
381 (15") 394 (15-1/2") 403 (15-7/8")
457 (18") 470 (18-1/2") 479 (18-7/8")
533 (21") 546 (21-1/2") 555 (21-7/8")
NL = Nominal slide length
2D locking device 3D locking device
Notching
for locking
device
