800.533.0533 426 Prices subject to change without notice.
Mc
Push-to-Open with Silent System
For Quadro 2D V6 IW 21 Silent-Closing Slide
Synchronization rod for cabinets wider
than 600 mm. Can be used from 275 mm.
Length = inside cabinet width -200 mm.
Push-to-open
mechanisms
Opens without handles, closes with Silent System
With Push-to-Open Silent, drawers are incredibly easy to open without handles, gently
and quietly closing again. Drawers can still be pulled open and guided closed. Instead
of springing back, Push-to-Open Silent stores energy and assists the closing cycle as
the drawer slowly glides in.
With the optional synchronization rod, the system can be activated from the edges of
large drawer fronts, even with narrow front panel reveals.
• Minimal 2.5 mm front panel reveal
• Drawer can still be guided closed & pulled open
• Clips into place without the need for tools
• For all nominal drawer lengths 12" - 24"
• Mechanism has two weight ranges to choose from
Set No.
Weight
Range
Nominal
Length List Set
15 to 45 lbs. 250 - 600 $87.64
25 to 90 lbs. 380 - 600 $87.64
Accessories
Synchronization Rod $17.28
Rod Connector $2.04
Synchronization Rod
2000 mm length can be cut to size. Recommended
for cabinet widths over 600 mm; can be used
from 275 mm. Aluminum, anodized.
Length = inside cabinet width -201 mm
Connector
Use to join two synchronization rods. Gray plastic.
Set includes
1 st Push-to-Open Silent unit, left & right
1 st Activator, left & right
2 ea Adapters for mounting optional synchronization rod
Synchronization Rod
Length = inside cabinet width -201 mm
Silent
System
