Charles McMurray Co. 2023 Catalog

1358c / 1645

Track
2000 mm (78-3/4") or
2500 mm (98-7/16")
single running, screw-on,
aluminum
2000 mm (78-3/4") or
2500 mm (98-7/16")
single running,
pre-drilled, ceiling
mounted, aluminum
2000 mm (78-3/4") or
2500 mm (98-7/16")
single running, pre-drilled,
wall mounted, aluminum
2500 mm (98-7/16")
single running,
pre-drilled, ceiling
integrated, aluminum
1300 mm (51-3/16")
groove mounted bottom
guide, plastic
Pocket/Sliding
05/24
For further information
on Hawa Junior 100B
visit:
Hawa Junior 100 B - Mortised
Pocket/Sliding Door System for Wood Doors
Surface Mount with Soft-Close
For standard or pocket door: Order hardware set, track and accessories separately.
Set No. Description List Set
Hawa Junior 100BHardware Set w/SoftMove * $905.86
Hawa Junior 100B Hardware Set w/SoftStop $704.18
*For SoftMove soft-close/soft-open, order (1) HW-JR100-SOFTMOVE, (1) included.
Upper track and bottom guide, sold per each. Mounting hardware not included.
Item No. Description List Ea.
Bottom guide - 1300 mm (51-3/16") $28.68
HW-JR-TRACK-78* 2000 mm (78-3/4") $216.56
HW-JR-TRACK-78CM Ceiling mount - 2000 mm (78-3/4") $227.04
HW-JR-TRACK-78WM Wall mount - 2000 mm (78-3/4") $264.56
HW-JR-TRACK-98* 2500 mm (98-7/16") $271.16
Ceiling integrated - 2500 mm (98-7/16") $366.52
HW-JR-TRACK-98CM Ceiling mount - 2500 mm (98-7/16") $283.80
HW-JR-TRACK-98WM Wall mount - 2500 mm (98-7/16") $330.72
*For use in pocket door application
• Maximum door weight: 220 lbs.
• Maximum door width
Pocket door application: 1500 mm (59-1/16")
Standard application: 3000 mm (118-1/8")
• Maximum door height: 4000 mm (157-1/2")
• Door thickness: 35-80 mm (1-3/8" to 3-3/16")
• Hardware for (1) top-running sliding door (suspension plate is mortised into door)
• Door installation from the side or front with height adjustment
• Optional aluminum clip-on fascia, SoftMove soft-close and accessories (order separately)
Soft-Close
SoftMove 100 magnetic
soft-close w/running
gear, end stop and
cover, pre-mounted
Sold per each. Order two per door for
soft-close/soft-open. Mounting hardware
included.
Item No. List Ea.
$379.46
Demountable Track Profile
2035 mm (80-1/8")
or 2535 mm (99-13/16")
retainer profile with
bayonet lock, aluminum
For pocket door application. Sold per each,
order one per door. Mounting hardware
included. (Order track separately.)
Item No.
Track
Length List Ea.
78-3/4" $307.72
98-7/16" $362.98
Hardware Set SM SS
2-wheel ball-bearing
running gear 1 2
SoftStop w/adjustable
retention spring* 1 1
Zero tolerance lower
guide, 7/16"W groove,
plastic
1 1
Suspension profile w/
screw and plate 1 1
Suspension profile w/
bolt, plate and locking
wrench
1 1
Spring loaded end
stop 1
SoftMove100magnetic
soft-close w/running
gear, end stop and
cover, pre-mounted
1
Mounting hardware included
Handed end caps, soldper each. Includes
(1) left or right end fascia with mounting
hardware.
Item No. Description List Ea.
HW-JR-30145 End fascia (L) $80.44
HW-JR-30146 End fascia (R) $80.44
Clip-on Fascia
2000 mm (78-3/4") panel
clips to running track,
aluminum
Fascia end, left, 2-1/8",
aluminum
Fascia end, right, 2-1/8",
aluminum
Panels, sold per each.
Item No. List Ea.
HW-JR-27689 $88.94
